Electronic Ballasts
T8 Instant Start, Standard <20% THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps Input
Voltage
Satco
Product
Number
Ballast Code
Pkg
Qty Wiring
Method
F96T8 2 120v S5211 S QT2X59/120/IS 10 Leads
2 277v S5212 S QT2X59/277/IS 10 Leads
Listed for FO96T8 and SS equivalents
Can operate 1 lamp on 2 lamp ballast
T8 Instant Start, Professional <10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty Wiring
Method
F96T8 2 120/277 S5213 S QT2X59T8/UNIV/ISN/SC 10 Leads
Listed for FO96T8 and SS equivalents
Can operate 1 lamp on 2 lamp ballast
T12 Rapid Start, < 10% THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps Input
Voltage
Satco
Product
Number
Ballast Code
Pkg
Qty Wiring
Method
F40T12 1 120 S5258 S QTP1X40T12/120/RSN B 20 Leads
277 S5259 S QTP1X40T12/277/RSN B 20 Leads
2 120 S5260 S QTP2X40T12/120/RSN B 20 Leads
277 S5261 S QTP2X40T12/277/RSN B 20 Leads
3 120 S5262 S QTP3X40T12/120/RSN B 20 Leads
277 S5263 S QTP3X40T12/277/RSN B 20 Leads
Listed for F34T12, FB34T12, F40T12, FB40T12, F40T10
FT40DL Instant Start, <20%THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps Input
Voltage
Satco
Product
Number Ballast Code
Pkg
Qty
Wiring
Method
FT40DL 1 120 S5240 S QT1X40/120/DL 10 Leads
2 277 S5241 S QT1X40/277/DL 10 Leads
1 120 S5242 S QT2X40/120/DL 10 Leads
2 277 S5243 S QT2X40/277/DL 10 Leads
1 120 S5244 S QT3X40/120/DL 10 Leads
2 277 S5245 S QT3X40/277/DL 10 Leads
