Electronic Ballasts
T8 Instant Start, Standard <20% THD, Dedicated Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number
Ballast Code
Pkg
Qty
Wiring
Method
F32T8
1
120v
S6623
S
QT1X32T8/120/ISN/SC
10
Leads
277v
S6633
S
QT1X32T8/277/ISN/SC
10
Leads
2
120v
S6624
S
QT2X32T8/120/ISN/SC
10
Leads
277v
S6634
S
QT2X32T8/277/ISN/SC
10
Leads
3
120v
S6625
S
QT3X32T8/120/ISN/SC
10
Leads
277v
S6635
S
QT3X32T8/277/ISN/SC
10
Leads
4
120v
S6626
S
QT4X32T8/120/ISN/SC
10
Leads
277v
S6636
S
QT4X32T8/277/ISN/SC
10
Leads
Listed for FBO16, FO17, FBO24, FO25, FBO31, FO32, FBO32, FO40 & SS Equivalents
Can operate 1 lamp on 2 lamp ballast, 2 lamps on 3 lamp ballast, 3 lamps on 4 lamp ballast
For F40T8 operation use 1 lamp on a 2 lamp ballast, 2 lamps on a 3 lamp ballast,
or 3 lamps on a 4 lamp ballast
T8 Instant Start, Professional <10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number
Ballast Code
Pkg
Qty
Wiring
Method
F32T8
1
120/277
S5207
S
QTP1X32T8/UNIV/ISN/SC
10
Leads
2
120/277
S5208
S
QTP2X32T8/UNIV/ISN/SC
10
Leads
3
120/277
S5209
S
QTP3X32T8/UNIV/ISN/SC
10
Leads
4
120/277
S5210
S
QTP4X32T8/UNIV/ISN/SC
10
Leads
Listed for FBO16, FO17, FBO24, FO25, FBO31, FO32, FBO32, FO40 & SS Equivalents
Can operate 1 lamp on 2 lamp ballast, 2 lamps on 3 lamp ballast, 3 lamps on 4 lamp ballast
For F40T8 operation use 1 lamp on a 2 lamp ballast, 2 lamps on a 3 lamp ballast, or 3 lamps
on a 4 lamp ballast
T8 Programmed (Rapid) Start, Professional <10% THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number
Ballast Code
Pkg
Qty
Wiring
Method
F32T8
1
120/277
S5286
S
QTP1X32T8/UNIV/PSN/TC
10
Leads
2
120/277
S5287
S
QTP2X32T8/UNIV/PSN/TC
10
Leads
3
120/277
S5288
S
QTP3X32T8/UNIV/PSN/SC
10
Leads
4
120/277
S5289
S
QTP4X32T8/UNIV/PSN/SC
10
Leads
Listed for FBO16, FO17, FBO24, FO25, FBO31, FO32, FBO32 & SS Equivalents
Can operate 1 lamp on 2 lamp ballast, 2 lamps on 3 lamp ballast, 3 lamps on 4 lamp ballast
