Electronic Ballasts
Compact Fluorescent Programmed Start, <10%THD, Universal Voltage Ballasts
Primary
Lamp
Type
No of
Lamps
Input
Voltage
Satco
Product
Number
Ballast Code
Pkg
Qty
Wiring
Method
CF13
1 / 2
120/277
S5223
S
QTP1/2X13CF/UNV/BS
20
Wiretap Connectors
S5225
S
QTP1/2X13CF/UNV/TS
20
Wiretap Connectors
Listed for 1 or 2 CF13DD/E or CF13DT/E lamp(s)
CF18
1 / 2
120/277
S5226
S
QTP1/2X18CF/UNV/BS
20
Wiretap Connectors
S5228
S
QTP1/2X18CF/UNV/TS
20
Wiretap Connectors
Listed for 1 or 2 CF18DD/E or CF18DT/E Lamp(s)
CF26
1 / 2
120/277
S5229
S
QTP1/2X26CF/UNV/BS
20
Wiretap Connectors
S5231
S
QTP1/2X26CF/UNV/TS
20
Wiretap Connectors
Listed for 1 or 2 CF26DD/E, CF26DT/E, FPC22T5, FT24DL, CF24DF Lamp(s)
Also Listed for 1 ea CF32DT/E, CF42DT/E, F28/2D, F38/2D, FPC40T5, FT40DL Lamp
Also Listed for 2 ea CF13DS/E, FT18DL/RS, CF18DF, F21/2D Lamps
CF26
1 / 2
120/277
S5232
S
QTP1/2CF/UNV/BM
20
Wiretap Connectors
S5233
S
QTP1/2CF/UNV/PM
18
Wiretap Connectors
S5234
S
QTP1/2CF/UNV/TM
18
Wiretap Connectors
Listed for 1 or 2 CF26DD/E or CF26DT/E Lamp(s)
Also Listed for 1 ea CF32DT/E or CF42DT/E
CF26
2
120/277
S5235
S
QTP2X26/32/42CF/UNV/BM
20
Wiretap Connectors
S5236
S
QTP2X26/32/42CF/UNV/PM
18
Wiretap Connectors
S5237
S
QTP2X26/32/42CF/UNV/TM
18
Wiretap Connectors
Listed for 2 ea CF26DT/E, CF32DT/E, CF42DT/E, FT36DL, FT40DL, FPC40T5 Lamps
Also Listed for 1 ea FPC22T5 plus FPC40T5 Lamps (must use both lamps together)
CF57
1
120/277
S5238
S
QTP1X57CF/UNV/BM
20
Wiretap Connectors
S5239
S
QTP1X57CF/UNV/PM
18
Wiretap Connectors
Listed for 1 ea CF57DT/E or CF70DT/E Lamp
Plastic Enclosure Styles (S)
BS = Bottom Mount for
recessed downlight
fixtures
TS = Top Mount for
ceiling and wall
sconce installation
Metal Enclosure Styles (S)
BM = Bottom Mount for
recessed downlight
fixtures
PM = Bottom Mount with
PEM studs for recessed
downlight fixtures
TM = Top Mount with PEM
studs for ceiling and
wall sconce installation
