40 Sun StorEdge 3900 and 6900 Series 2.0 Troubleshooting Guide • March 2003
Sun Proprietary/Confidential: Internal Use Only
TABLE 5-2 and FIGURE 5-2 shows the basic components and the FC links for a Sun
StorEdge 6900 series system:
TABLE 5-2 Ax to Bx FC Links.
Link Provides FC Link Between These Components
A1 to B1 HBA to Sun StorEdge network FC switch-8 and switch-16
switch link
A2 to B2 Sun StorEdge network FC switch-8 and switch-16 switch to
virtualization engine link on the host side
A3 to B3 Sun StorEdge network FC switch-8 and switch-16 switch to the
virtualization engine link on the device side
A4 to B4 Sun StorEdge network FC switch-8 and switch-16 switch to Sun
StorEdge T3+ array link
T1 to T2 T port switch-to-switch link
