Hardware installation, Package contents, Board layout – SIIG 04-0265F User Manual
Page 2
2
Package Contents
•
Serial ATA PCI adapter
•
Driver CD
•
Serial ATA cable
•
Serial ATA power cable
•
Quick installation guide
Board Layout
Figure 1. Serial ATA PCI Board Layout
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
CN1
CN2
Serial ATA
connector
