Model W1796/W1797 2-Gun Spray Set
-16-
W1796 PARTS LIST
REF PART�# DESCRIPTION REF PART�# DESCRIPTION
1 X1796001 FLUID�ADJ.�SCREW 49 X1796049 AIR�INLET�VALVE
2 X1796002 FLUID�ADJ.�SEAT 50 X1796050 SWITCH�SPRING
3 X1796003 O-RING�2.5�X�2.1 51 X1796051 AIR�INLET�VALVE
4 X1796004 WASHER 52 X1796052 FOAM�WASHER
5 X1796005 AIR�VALVE�SPRING 53 X1796053 O-RING�8.5�X�1.2
6 X1796006 AIR�INLET�VALVE 54 X1796054 SWITCH�SEAT
7 X1796007 SWITCH�SPRING 55 X1796055 SEALING�WASHER
8 X1796008 AIR�INLET�VALVE 56 X1796056 PLIABLE�WASHER
9 X1796009 FOAM�WASHER 57 X1796057 LOCK�SCREW
10 X1796010 O-RING�4.9�X�1.5 58 X1796058 LOCKED�SPRING
11 X1796011 SWITCH�SEAT 59 X1796059 AIR�CAP�NUT
12 X1796012 SEALING�WASHER 60 X1796060 AIR�CAP�WASHER
13 X1796013 LOCK�SCREW 61 X1796061 AIR�CAP
14 X1796014 AIR�CAP�NUT 62 X1796062 FLUID�NOZZLE
15 X1796015 AIR�CAP�WASHER 63 X1796063 FLUID�NOZZLE�PLUG
16 X1796016 AIR�CAP 64 X1796064 NOZZLE�PLUG�WASHER
17 X1796017 O-RING�17�X�1.5 65 X1796065 JOINT�WASHER
18 X1796018 FLUID�NOZZLE 66 X1796066 DIRECTION�SCREW
19 X1796019 FLUID�GASKET 67 X1796067 SPECIAL�WASHER
20 X1796020 NOZZLE�SCREW 68 X1796068 NEEDLE�WASHER
21 X1796021 NEEDLE�WASHER 69 X1796069 SEALING�WASHER
22 X1796022 SEALING�WASHER 70 X1796070 COMPRESSION�SPRING
23 X1796023 COMPRESSION�SPRING 71 X1796071 TRIGGER�LEVER�II
24 X1796024 TRIGGER�LEVER�II 72 X1796072 TRIGGER�LEVER�I
25 X1796025 TRIGGER�LEVER�I 73 X1796073 TRIGGER
26 X1796026 TRIGGER 74 XPEC02M E-CLIP�4MM
27 XPEC02M E-CLIP�4MM 75 X1796075 TRIGGER�WASHER
28 X1796028 CONTAINER�COVER 76 X1796076 BREATHER�PLUG
29 X1796029 CONTAINER�100ML 77 X1796077 CONTAINER�COVER
30 X1796030 FILTER 78 X1796078 CONTAINER�600ML
31 X1796031 FLUID�INLET�JOINT 79 X1796079 FILTER
32 X1796032 NEEDLE 80 X1796080 FLUID�INLET�JOINT
33 X1796033 COMPRESSION�SPRING 81 X1796081 FLUID�NEEDLE
34 X1796034 FLUID�ADJ.�JOINT 82 X1796082 FLUID�NEEDLE�SPRING
35 X1796035 FLUID�ADJ.�KNOB 83 X1796083 JOINT�CAP
36 X1796036 FLAT�HD�SCR�M2.5-45�X�8 84 X1796084 FLUID�ADJ.�KNOB
37 X1796037 PATTERN�ADJ.�SCREW 85 XPFH25M FLAT�HD�SCR�M4-.7�X�12
38 X1796038 PATTERN�ADJ.�LEVER 86 X1796086 ADJUSTMENT�KNOB
39 X1796039 O-RING�2�X�1.5 87 X1796087 PATTERN�ADJ.�SCREW
40 X1796040 E-CLIP�2.5MM 88 X1796088 PATTERN�ADJ.�LEVER
41 X1796041 PATTERN�ADJ.�SEAT 89 X1796089 PATTERN�ADJUSTER
42 X1796042 GUN�BODY 90 X1796090 O-RING�6�X�2
43 X1796043 AIR�INLET�PLUG 91 X1796091 GUN�BODY
44 X1796044 FLUID�ADJ.�SCREW 92 X1796092 AIR�INLET�PLUG
45 X1796045 FLUID�ADJ.�KNOB 93 X1796093 BAFFLE�WRENCH
46 X1796046 O-RING�2.5�X�2.1 94 X1796094 TOOL�WRENCH
47 X1796047 VALVE�WASHER 95 X1796095 REGULATOR
48 X1796048 AIR�VALVE�SPRING 96 X1796096 COMPLETE�O-RING�SET
