SPECIFICATION KEY
2.2 A–1
OUTPUT POWER RATINGS
ƒ
40 kVA/ 36 kW
ƒ
50 kVA/ 45 kW
ƒ
60 kVA/ 54 kW
ƒ
80 kVA/ 72 kW
ƒ
100 kVA/ 90kW
ƒ
130 kVA /117kW
2.2 A-3 / A-4 INPUT / OUTPUT VOLTAGES
ƒ
480V Core Voltage Only
2.2 A-5
BATTERY BACK-UP TIME
(minutes)
Configuration Battery 40
kVA 50
kVA 60
kVA 80
kVA 100
kVA 130
kVA
1 x Level 3 NPX-150 11 9 x x X X
1 x Level 4 300 WPC 28 22 16 10 x x
1 x Level 5 400 WPC 41 31 24 16 11 7
1 x Level 6 500 WPC 59 46 36 25 17 11
2 x Level 5 400 WPC 90 72 57 41 31 22
2 x Level 6 500 WPC X x 81 58 47 33
3 x Level 6 500 WPC X x 127 94 71 54
Additional configuration and runtimes are available.
2.2 B-2
INPUT CURRENTS
40 KVA 50 KVA 60 KVA 80 KVA 100
KVA
130
KVA
A @ 480 VAC
Max – Charging Battery
59 70 88 111 150 182
2.2 B-2
OUTPUT CURRENTS
40 KVA 50 KVA 60 KVA 80 KVA 100
KVA
130
KVA
A @ 480 VAC 48 60 72 96 120 156
APC – MGE Galaxy 5000 Specification (60Hz) 15 Effective: June 1, 2008 REV X0 JJG
