A
WARNING
Before installing the kit or making any adjustments:
disengage the PTO; set the parking brake; stop the
engine and remove the key.
A
WARNING
When disconnecting the battery cables, always
disconnect the negative cable W h e n
connecting cables, always connect the negative
cable last. The positive terminal can easily be
shorted to the frame with tool if this is not done.
Do not touch any wires or electrical components
such as the solenoid, unless the battery cables
INSTALLATION
1. Park tractor on flat, level surface. Turn tractor off.
Disengage PTO, and allow all moving parts to stop.
Engage the parking brake.
Disconnect the battery cables and position away
from terminals.
gasoline may ignite. Insure clamps grip hose firmly
A
WARNING
Handle gasoline with care. It is highly flammable.
Use an approved gasoline container.
3. Drain the fuel tank as follows.
a. Place an approved gasoline container below the
fuel
b. Use a pliers to spread the fuel filter clamps and
slide away from filter. Do not spread more than
necessary.
Pull hoses off and allow gasoline to drain
into container.
4. Raise rear right-hand side of tractor up and place
under
Remove rear right-hand wheel assembly.
Remove from wheel assembly and
secure kit hub assembly (0, figure 1) to wheel. Do not
install on tractor.
Prepare template (provided on last page) by cutting
out all dashed areas. Use this template to drill five
1 holes in wrapper.
Install rear actuator bracket (X, 1 or A, figure
2) with two capscrews (T, figure spacers
lockwashers (D), and nuts (R). Install bolts from
outside in, putting spacers between bracket and
wrapper. Lockwashers and nuts
installed on
inside of wrapper. Do not install the
(W) at this time.
9. Install front bracket (C, figure 2) with bottom
(B) only. Install from inside out.
,
Secure with lockwasher (D, and nut (R).
Figure 2. Bracket Installation
Rear Bracket
1” capscrews
C. Front Bracket
10. Insert cylinder (A, figure 3) through brackets as
shown in 3. securely into
rear bracket slots.
1 1 . Install top 4-l (C) on rear bracket (with
spacer between bracket and wrapper) and secure
with locknut (V, I). Install top
3, from inside wrapper) in front bracket and
secure with lockwasher and nut.
