Back Panel Overview
17
1 Mouse connector
Connects a PS/2 mouse.
2 PS/2® Keyboard connector
Connects a VAIO Smart™ Keyboard.
3 Ethernet connector
10Base-T/100Base-TX Fast Ethernet interface.
The connector marked with
(Network) is for LAN connections only.
4 Universal Serial Bus (USB) connectors
Connects a USB device.
5 Printer connector
Connects a parallel device, such as a printer or scanner.
6 Serial connector
Connects a compatible serial device, such as a digital still camera.
7 i.LINK 6-pin connector (IEEE1394)
Connects a compatible digital device such as a Sony Digital Handycam
®
Camcorder.
8 Game connector
Connects a game or MIDI device.
9 Headphones connector
Connects the supplied speakers or optional headphones.
10 Line In connector
Connects an audio device.
11 Microphone connector
Connects a microphone (optional).
12 Monitor connector
Connects a standard CRT display.
13 Line jack
Connects the supplied modem cable to the wall jack.
14 AC Input connector
Connects the supplied power cord.
15 DVI (LCD) Monitor connector
Connects an LCD monitor.
16 Telephone cable jack
Connects the phone cable to the computer.
