Back Panel Overview
15
1 Mouse connector
Connects a PS/2 mouse.
2 PS/2® Keyboard connector
Connects a VAIO Smart™ Keyboard.
3 Universal Serial Bus (USB) connector
Connects a USB device.
4 Printer connector
Connects a parallel device, such as a printer or scanner.
5 Serial connector
Connects a compatible serial device, such as a digital still camera.
6 Monitor connector
Connects a standard CRT display.
7 Game connector
Connects a game or MIDI device.
8 Headphones connector
Connects the supplied speakers or optional headphones.
9 Line In connector
Connects an audio device.
10 Microphone connector
Connects a microphone (optional).
11 i.LINK 6-pin connector (IEEE1394)
Connects a compatible digital device such as a Sony Digital Handycam
®
Camcorder.
12 Line jack
Connects the supplied modem cable to the wall jack.
13 AC Input connector
Connects the supplied power cord.
14 Ethernet connector
10Base-T/100Base-TX Fast Ethernet interface.
The connector marked with
(Network) is for LAN connections only.
15 Telephone cable jack
Connects the phone cable to the computer.
