Model SB1037F Page 1 of 4
Model SB1037F
South Bend 16" x 40" Lathe 220V with DRO
Product Dimensions
Weight........................................................................................................................................................... 3107 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 86 x 33 x 60 in.
Footprint (Length x Width)................................................................................................................. 82 x 19-1/2 in.
Shipping Dimensions
Type.................................................................................................................................................. Wood Slat Crate
Content.......................................................................................................................................................... Machine
Weight........................................................................................................................................................... 3374 lbs.
Length x Width x Height.................................................................................................................... 94 x 45 x 69 in
Electrical
Power Requirement................................................................................................................. 220V, 3-Phase, 60 Hz
Full-Load Current Rating................................................................................................................................. 21.7A
Minimum Circuit Size.......................................................................................................................................... 30A
Inverter Type............................................................................................................................... Yaskawa G7A25P5
Switch................................................................................................................. Magnetic with Thermal Protection
Switch Voltage.................................................................................................................................................... 220V
Plug Included.......................................................................................................................................................... No
Recommended Plug/Outlet Type.................................................................................................................... L15-30
Motors
Main
Type........................................................................................................................................ TEFC Induction
Horsepower......................................................................................................................................... 7-1/2 HP
Voltage...................................................................................................................................................... 220V
Phase.................................................................................................................................................... 3-Phase
Amps........................................................................................................................................................... 20A
Speed.......................................................................................................................................... 0 – 4500 RPM
Cycle......................................................................................................................................................... 60 Hz
Number of Speeds............................................................................................................................... Variable
Power Transfer ......................................................................................................................... V-Belt & Gear
Bearings.................................................................................................... Shielded and Permanently Sealed
-2-
Mfg. Since 4/11 Model SB1037F M A N U A L I N S E R T
