17
Section 8
ENGINE AND ATTACHING PARTS
42
1 483439 Engine, Briggs & Stratton 26hp ELS
483401 Engine, Briggs & Stratton 23hp Vanguard
483685 Engine, Kohler Command 25hp
2 423770 Bumper, Rear
3 424107 Shield, Rear (48” & 52”)
41031 Weight, Rear Shield ( 61” Only)
4 04019-04 Nut, Serr. Flange 3/8-16
5 482510 Extension, Oil Drain 3.3”
6 04003-23 Bolt, Carr. 3/8-16 x 1”
7 04104-01 Bolt, 3/8-16 x 1” Torx
8 483288 Muffler, Briggs & Stratton 26ELS
483416 Muffler, Briggs & Stratton 23hp Vanguard
483266 Muffler, Kohler
9 424133 Bracket, Muffler
10 423555 Plate, Skid
11 04001-11 Bolt, Hex Head 5/16-18 x 1-1/2”
12 04001-19 Bolt, Hex Head 3/8-16 x 1”
13 04011-12 Screw, Hex Head 5/16-18 x 3/4” Self Tap
14 483280-01 Tubing, Oil Drain 1/2” x 8”
15 04003-31 Bolt, Carr. 3/8-16 x 3/4”
16 04019-03 Nut, Serr. Flange 5/16-18
17 424415 Guard, Carb Inlet
Ref. Part
No.
No. Description
