Page 32
24
Section 3A. Technical Specifications
Radio Frequency and Electrical Specifications
Blue, blinking
Sprint Power Vision
®
(1xEV-DO) coverage is detected. Ready to connect to
the network; see the user guide.
Blue, not
blinking
The USB modem is connected to the Sprint Power Vision (1xEV-DO)
network and can send or receive data.
Approvals
Compliant with:
IS-2000 Release 1.0 (CDMA (1X), IS-707-A Data, IS-856 (CDMA 1xEV-DO), IS-
866, IS-878, IS-890, CDMA Development Group
FCC (ID: N7NC597)
Industry Canada (ID: 2417C-C597)
Voltage
+5.0 Vdc from USB slot
Current
Maximum: 550 mA (from USB port)
Typical data call current (talk mode):
330 mA (1X)
410 mA (1xEV-DO)
Standby:
60 mA (1xEV-DO/IS-2000 hybrid mode)
Transmitter power
250 mW (+24 dBm) average
Transmit
PCS: 1850 to 1909.95 MHz
Cellular: 824.04 to 848.97 MHz
LED
State of LED
Indicates
