Sony ZS-SN10 - Manual (Page 2)

ZS-SN10SILVER
MP3 CD Boombox
Last Updated: 03/02/2006
Please visit the Dealer Network for current information at www.sony.com/dn
Features
Plays Back CD-R/RW Discs with
MP3/ATRAC3®/ATRAC3plus™ Audio For customers who already
have extensive music libraries, use the included software and hardware
to manage, burn and playback their collection of MP3s. ATRAC3plus is
an advanced audio compression technology offering multiple bit rates,
allowing you to create music compilations tailored to your listening
preference with the ability to get up to 490 songs on 1 CD-R/RW disc @
48kbps. 1
2
PC/Audio In for Digital Music Players or PC Input An exciting new
feature that takes music playback beyond tape and CD. It allows simple
plug-and-play integration with a digital music device or PC via a 2.5 mm
jack.
Music Management Software Supplied is easy to use and allows
you to create your own ATRAC3plus music file compilations on CD-R/RW
media using your PC's CD Burner. The ability to add your own titles and
edit your music groups allows for an element of customization in your
portable music
Jog-Lever Operation for Music Search Means you scroll by turning
the Jog Dial to find the track you're looking for.
2 Line Dot Matrix Display Provides ID3 tag information for fast and
easy identification and location of your ATRAC or MP3 selections and
makes it easy to search all music files even in another folder layer.
Digital AM/FM Stereo Tuner provides the most accurate drift-free
tuning of AM and FM radio stations and lets you choose from the wide
variety of talk shows and music programs, with the added enjoyment of
stereo sound.
10-Key Direct Access™ Remote Control Full sized remote control
including keys to directly access tracks on a CD as well as preset stations
programmed into tuner memory.
AC/DC Operation Power your boombox by batteries or use the
supplied AC adapter
Mega Bass® Sound System produces rich, deep, bass tones for
more powerful overall sound.
4 Sound Modes Plus a Custom Mode for Personalized
Sound Jazz, Rock, Pop and Vocal Modes plus one customizable mode.
30 Station Memory Presets (10AM/20FM) with Personalized uses
electronic settings for easy, one-button tuning of your choice of 10AM or
20FM stations.
CD Play Modes (Program/Shuffle/Repeat) lets you hear tracks in
multiple modes; in sequence as recorded, in program (RMS) order, all
tracks in random (shuffle) order or a single track over and over.
Compatible with the Connect™ Music Store Offers one of the
most extensive music collections online. Unique features such as
Moodmix, Connect Sets and live radio, make this a choice destination for
customers looking to expand their music collection. It's easy to discover,
find and purchase single tracks or entire albums. Choose from top hits
and tracks from independent artists.
Specifications
General
Type of Use: Portable Boombox
Disc Changer: 1
Tray Type: Top Loading Single CD
Audio
Digital-to-Analog Converter: 1 Bit
Frequency Response: CD: 20-20000Hz (+0/-1dB)
Format(s) Supported: CD-DA, CD-R/RW with MP3/ATRAC3®/
ATRAC3plus™ Audio
Tuning: Auto Scan Radio
Antenna System: AM: Built-in Ferrite Bar Antenna; FM: Telescopic Antenna
Frequency Range: AM: 530-1710kHz; FM: 87.5-108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat, 20 Track RMS Programming
Station Preset(s): 30 (10 AM, 20 FM)
Sound Enhancer: Mega Bass®
Equalizer: 5 Presets (Rock, Pop, Jazz, Vocal, Custom)
Tuner Type: Digital
Hardware
Display: 2 Line Dot Matrix
Remote Control: Yes
Power
Battery Life (Approx.): Unit: up to 25 hours (with Sony® Alkaline Batteries)
Power Requirements: AC 120V, 60Hz
Output Power: 4.6 W Total (2.3W + 2.3W (at 3.2 ohms, 10% harmonic
distortion))
Power Consumption: 16W
Battery Type: Unit: "D" x 6 (optional); Remote: "AAA" x 2
Power Handling Capacity: With 3.2-ohm loads, both channels driven
from 150-6300Hz; rated 1.8 W per channel minimum RMS power, with no
more than 10% total harmonic distortion in AC operation.
Speaker
Speaker System: Built-In Stereo
Speaker Dimensions: 4" (10cm) x 2
Software
Supplied Software: SonicStage®
Inputs and Outputs
Headphone Input(s): 1
DC-In: 1
PC Audio Input(s): Yes
Dimensions
Weight: 8 lbs 6 oz (3.8 Kg)
Measurements: 19 11/16 x 5 5/7 x 9 1/16" (500 x 145 x 230mm)
Supplied Accessories
AC Power Cord
Remote Control
Color: Black
UPC Code: 027242692916
1. CD-R/RW media/formats are not universally compatible.
2. Estimated at 4 minutes per song, using 700MB CD-R/RW media, compressing in ATRAC3plus @48kbps.
©2006 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited. All rights reserved. Sony, ATRAC3plus,
Connect, Direct Access, Psyc, Remote Commander, and like.no.other are trademarks of Sony.
Features and specifications are subject to change without notice. Non-metric weights and measures are
approximate.
