DVR-X1 User Manual
2. Specification
Operation Mode Front panel, OSD
Recording Speed 720 x 240 : 1–10 Frames/sec (adjustable)
360 x 240 : 1–15 Frames/sec (adjustable)
Recording Mode Manual
Schedule
Motion Detection (Sensitivity Adjustable)
External Sensor
Audio Recording /
Live Audio 1 ch
Compression MJPEG
Video Input 1 channel BNC (NTSC/PAL)
Video Output Composite video (BNC) x 2
Playback Function
Playback — forward 、reverse
Fast forward
Fast reverse
Forward one frame
Zoom in
HDD 40 GB(standard) or 80 GB (optional)
Built-in Buzzer Video loss alarm
Motion Detection
External Sensor
Watch-Dog Function Automatically returns to the original
operation after a power failure.
Search Mode Date, Time, Alarm
Operation Temperature 32 degrees F to 110 degrees F
Power Supply 100V~240V AC, 50/60Hz
DC 12V/4A
Power Consumption 12 W
Dimension 313mm x 255mm x 44mm (W x D x H)
Weight 3.0Kg
3
