Scag Power Equipment GC-STC-CS - Manual (Page 13)

11
GC-STC 48" & 52" BLOWER MOUNTING COMPONENTS
Ref. Part
No. Number Description
1 482612 Belt Cover, GC-STC
2 04029-04 Wingnut, Plastic 3/8" Small
3 482300 Cap, Square Vinyl
4 04021-08 Nut, Elastic Stop 1/4-20
5 461723 Adapter, Blower GC-STC, includes item #7
6 04040-14 Flatwasher, 1/4-.312 x .750 x .065
7 48137-04 Rubber Strap 7-3/4"
8 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4"
9 481625-01 Knob W/Stud, 3/8-16 x 1-1/4"
10 04064-15 Clevis Pin, 5/16 x 1-1/2"
11 04069-03 Pin, Rue Cotter 5/16 Dia.
12 04067-07 Pin, Ring 1/2 x 2-1/4"
13 481547 Lanyard
14 482587 Pulley, 4.0" Dia. 1.125 Bore
15 04012-04 Setscrew, 5/16-18 x 3/8"
16 04021-09 Nut, Elastic Stop 3/8-16
17 04030-04 Lockwasher, 3/8"
18 04041-07 Flatwasher, 3/8-.391 x .938 x .105
19 04003-11 Bolt, Carr. 3/8-16 x 1-1/4" Grade 5
20 451693 Mounting Post Weldment, Blower
21 423708 Belt Cover
22 04110-03 U-Nut
23 04017-05 Bolt, Hex Head 1/4-20 x 3/4"
24 04003-23 Bolt, Carriage 3/8-16 x 1"
25 04021-09 Nut, Elastic Stop 3/8-16
26 04041-07 Flatwasher, 3/8-.391 x .938 x .105
27 04001-09 Bolt, Hex Head 5/16-18 x 1"
28 04040-15 Flatwasher, 5/16-.375 x .875 x .083
29 04021-10 Nut, Elastic Stop 5/16-18
30 04019-02 Nut, Serrated Flange 1/4-20
31 423633 Baffle, 48"
423629 Baffle, 52"
32 423955 Baffle, Turbo 48" Deck
423956 Baffle, Turbo 52" Deck
