Hmec 26-kp, -v-kp, -bv-kp, -b-k, -bv-k – Sennheiser 502399 User Manual
Page 25
23
HMEC 26-KP, -V-KP, -BV-KP, -B-K, -BV-K
HMEC 26-KP
1 Audio Hi
1 NoiseGard™ (DC+)
2 not assigned
2 Microphone Hi
3 Audio Lo / DC–
3 Microphone Lo
HMEC 26-V-KP / -BV-KP
1 Audio Hi left
1 NoiseGard™ (DC+)
2 Audio Hi right
2 Microphone Hi
3 Audio Lo / DC–
3 Microphone Lo / DC–
HMEC 26-B-K
1 Audio Hi
1 not assigned
2 not assigned
2 Microphone Hi
3 Audio Lo
3 Microphone Lo
HMEC 26-BV-K
1 Audio Hi left
1 not assigned
2 Audio Hi right
2 Microphone Hi
2 Audio Lo
2 Microphone Lo
1/4" (6.3 mm) jack plug
PJ-068 equivalent
1 2
3
1 2
3
