CVQ1000 3
SVAT ELECTRONICS
now you can see
P P ARTS OF THE SYSTEM ARTS OF THE SYSTEM
PARTS OF THE CAMERA
A. Mounting Bracket
B. IR LED
C. Camera Din Connector
D. Camera Lens
PARTS OF THE SWITCHER
1. Power LED.
2. Zoom LED.
3. Freeze / Auto scan LED.
4. Ok / Enter Button.
5. Freeze / Auto Scan Button.
6. Infrared Receiver.
7. Camera 1 Button.
8. Camera 2 Button.
9. Camera 3 Button.
10. Camera 4 Button.
11. Quad / Menu / ESC
12. Output Jack to Monitor or TV Video Input
13. Camera Connector
14. Camera Connector
15. Camera Connector
16. Camera Connector
17. Adapter Jack
PARTS OF THE REMOTE
1. Menu
2. Freeze
3. Zoom
4. Auto
5. Quad. Mode
6. PIP 2
7. PIP 1
8. Separate Camera
9. Camera 1
10. Camera 2
11. Camera 3
12. Camera 4
13. Enter
14. Move Up
15. Move Left
16. Move Down
17. Move Right
