Page 6
6
2
Connect the FM/AM antennas.
Set up the AM loop antenna, then connect
it.
Jack type
A
1
Connect the speakers.
Connect the speaker cords to the SPEAKER
terminals as shown below.
Getting Started
Hooking up the system
Do the following procedure 1 to 3 to hook up your system using the supplied cords and
accessories.
3
1
2
2
FM antenna
SPEAKER
(IMPEDANCE USE 8
Ω
)
L
R
Red (
3
)
Insert only the
stripped portion.
Black (
#
)
AM loop
antenna
AM loop antenna
Extend the FM lead
antenna horizontally.
Left speaker
Right speaker
FM
AN
T
75
Ω
CO
AXI
AL
AM
AN
T
