installing the Cradle Stand
1. Insert the stand so that it fi ts into the hole
as described in the fi gure.
2. Turn the stand clockwise to lock it.
(Turning it counter-clockwise will loosen
from the hole.)
3. This is the completion of the stand
installation.
1 1
2 2
Speaker Components
SUBWOOFER STAND BASE FRONT
SCREW (Large): 4EA SCREW (Small): 6EA
CRADLE STAND/
WALL MOUNT
REAR
CENTER
REAR
CENTER
HOLE COVER
REAR
CENTER
(L) (R)
STAND
(L) (R)
Ht-tWZ312
SUBWOOFER STAND BASE FRONT
SCREW (Large): 8EA SCREW (Small): 12EA
CRADLE STAND/
WALL MOUNT
CENTER
HOLE COVER
CENTER
(L) (R)
STAND
Ht-tWZ315
REAR
(L) (R)
CENTER
