Page 8

Symbol

Name

Designation/Explanation

Direct current

Type or a characteristic
of current

Alternating or

Type or a characteristic

direct current

of current

Class II construction

Designates Double
Insulated Construction tools.

Earthing terminal

Grounding terminal

Warning symbol

Alerts user to
warning messages

Li-ion RBRC seal

Designates Li-ion

program

battery recycling

This symbol designates
that this tool is listed by
Underwriters Laboratories.

This symbol designates
that this tool is listed
by the Canadian
Standards Association.

This symbol designates that this
tool is listed to Canadian Standards
by Underwriters Laboratories.

This symbol designates that
this tool complies to NOM
Mexican Standards.

This symbol designates that
this tool is listed by Underwriters
Laboratories, and listed to
Canadian Standards by
Underwriters Laboratories.

FUNCTIONAL DESCRIPTION

AND SPECIFICATIONS

Battery tools are always in
an operative condition.

Be aware of the possible hazards.

WARNING

FIG. 1

FORWARD/

REVERSING

LEVER &

TRIGGER

LOCK

CHARGER

FORWARD/REVERSE

INDICATOR LIGHTS

RUBBERIZED

GRIP

CHARGING

INDICATOR

LIGHT

SITE-LIGHT™

BIT

STORAGE

TRIGGER

ASSORTED

BITS WITH

REMOVABLE

BIT HOLDER

MOUNTING

SLOTS

Palm Size Cordless Screwdriver
