PARTS LIST
6-30
TA1-2
*2
07650048
TRANSISTOR ARRAY STA471A=S
2
#2
07650056
TRANSISTOR ARRAY UPA1428AH
2
TA3
NOT MOUNTED :SP212/6
#3
07650037
TRANSISTOR ARRAY TH3C10
1
:SP242/246
TR1
07320111
TRANSISTOR 2SD2011
1
TR2
07227853
TRANSISTOR 2SC1740SE
1
TR3
07009502
TRANSISTOR 2SA950
1
TR4-10
NOT USED
TR11
#1
07320101
TRANSISTOR 2SD2010
1
SP216/246
TR12
NOT USED
TR13
07320101
TRANSISTOR 2SD2010
1
REG1
08202011
IC-REG UPC7824
1
D1-2
08000040
DIODE DSM1D1
2
D3
#1
08000040
DIODE DSM1D1
1
SP216/246
D4
08000040
DIODE DSM1D1
1
LED1-2
08300136
LED SLZ-390B
2
RA1
06584723
RESIS. ARRAY 4.7K-OHM 1/8W 8EL
1
RA2
NOT MOUNTED
RA3
06581036
RESIS. ARRAY 10 K-OHM 1/8W 5EL
1
RA4
06584723
RESIS. ARRAY 4.7K-OHM 1/8W 8EL
1
RA5
NOT MOUNTED
RA6
NOT USED
RA7
06581023
RESIS. ARRAY 1 K-OHM 1/8W 4EL
1
RA8
06581026
RESIS. ARRAY 1 K-OHM 1/8W 7EL
1
RA9
06581030
RESIS. ARRAY 10 K-OHM 1/8W 3EL
1
RA10
06581824
RESIS. ARRAY 1.8K-OHM 1/8W 6EL
1
R11
06581032
RESIS. ARRAY 10 K-OHM 1/8W 8EL
1
CA1
05651012
CAPA. ARRAY 100PF 50V 8EL
1
CA2-3
05652212
CAPA. ARRAY 220PF 50V 8EL
2
CA4
05651012
CAPA. ARRAY 100PF 50V 8EL
1
CN1
09100582
CONNECTOR 57GE-40360-751
1
CN2
09100567
CONNECTOR 95003-2661
1
CN3
09100495
CONNECTOR HLEM23S-1
1
CN4
09100317
CONNECTOR 5483-04A
1
CN5
NOT USED
CN6
NOT MOUNTED :SP212/6
#3
09100038
CONNECTOR 5045-05A
1
:SP242/246
DSW1
09090034
DIP SWITCH KSS08-1
1
SW1-2
09010055
PUSH SWITCH SKHHLN
2
X1
09250047
CERA. OSCILLATOR CST8.0MTW
1
L1-4
09990705
BEADS INDUCTOR B01-RT
4
JA3
#3
06750004
CHIP RESISTOR 0 OHM 1/10W
1
F1
NOT MOUNTED :SP212/6
#3
09991023
FUSE RXE030*
1
:SP242/246
DRWG.NO. REV. PARTS NO.
PARTS NAME
Q’TY
REMARKS
RANK
Main Logic Board (Parallel Interface)
