PARTS LIST
6-22
6.5.1.2 Parts List
DRWG.NO. REV. PARTS NO.
PARTS NAME
Q’TY
REMARKS
RANK
Main Logic Board (Serial Interface)
IC1
08222026
EPROM 27256-150NS
1
SP2S.F.**
IC2
*3
08210142
TTL IC 74LS05FP*TL
1
#3
08210126
TTL IC 74LS05FP*EL
1
IC3
*3
08200155
IC-I/F HD151232FP*TL
1
#3
08200157
IC-I/F ADM232LJR*SOL16
1
IC4
*3
08210141
TTL IC 74LS04FP*TL
1
#3
08211037
TTL IC 74LS04FP*EL
1
IC5
*3
08210143
TTL IC 74LS32FP*TL
1
#3
08211038
TTL IC 74LS32FP*EL
1
IC6
08250018
CPU M37732S4AFP
1
IC7
NOT MOUNTED
IC8
*3
08210142
TTL IC 74LS05FP*TL
1
#3
08210126
TTL IC 74LS05FP*EL
1
IC9
08200109
IC-RESET M51953BL
1
R1
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R2
06054714
RD RESISTOR 470 OHM 1/6W
1
R3-4
NOT USED
R5
06054714
RD RESISTOR 470 OHM 1/6W
1
R6-7
06052211
RD RESISTOR 220 OHM 1/6W
2
R8
06058224
RD RESISTOR 8.2 K-OHM 1/6W
1
R9
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R10
06058224
RD RESISTOR 8.2 K-OHM 1/6W
1
R11
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R12
06058224
RD RESISTOR 8.2 K-OHM 1/6W
1
R13
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R14
06051034
RD RESISTOR 10 K-OHM 1/6W
1
R15
06058224
RD RESISTOR 8.2 K-OHM 1/6W
1
R16
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R17
06058224
RD RESISTOR 8.2 K-OHM 1/6W
1
R18-20
06051034
RD RESISTOR 10 K-OHM 1/6W
3
R21
06053314
RD RESISTOR 330 OHM 1/6W
1
R22-23
06054714
RD RESISTOR 470 OHM 1/6W
2
R24
06053314
RD RESISTOR 330 OHM 1/6W
1
R25-26
06051535
RD RESISTOR 15 K-OHM 1/6W
2
R27
06054714
RD RESISTOR 470 OHM 1/6W
1
R28-29
06051044
RD RESISTOR 100 K-OHM 1/6W
2
R30
06051034
RD RESISTOR 10 K-OHM 1/6W
1
R31-39
06053314
RD RESISTOR 330 OHM 1/6W
9
R40
#1
06053314
RD RESISTOR 330 OHM 1/6W
1
SP216
R41-42
06054725
RD RESISTOR 4.7 K-OHM 1/6W
2
R43
06052234
RD RESISTOR 22 K-OHM 1/6W
1
R44
06054714
RD RESISTOR 470 OHM 1/6W
1
R45-47
06051034
RD RESISTOR 10 K-OHM 1/6W
3
R48
06054714
RD RESISTOR 470 OHM 1/6W
1
R49
06052224
RD RESISTOR 2.2 K-OHM 1/6W
1
R50
06051034
RD RESISTOR 10 K-OHM 1/6W
1
R51
06251034
RN RESISTOR 10 K-OHM 1/6W
1
R52
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R53
06051525
RD RESISTOR 1.5 K-OHM 1/6W
1
R54
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R55-56
06054714
RD RESISTOR 470 OHM 1/6W
2
R57-58
06054725
RD RESISTOR 4.7 K-OHM 1/6W
2
R59-60
06051034
RD RESISTOR 10 K-OHM 1/6W
2
