PARTS LIST
6-23
Main Logic Board (Serial Interface)
DRWG.NO. REV. PARTS NO.
PARTS NAME
Q’TY
REMARKS
RANK
R61
06054725
RD RESISTOR 4.7 K-OHM 1/6W
1
R62
06051051
RD RESISTOR 1 M-OHM 1/6W
1
R63
06052211
RD RESISTOR 220 OHM 1/6W
1
R64-65
06054725
RD RESISTOR 4.7 K-OHM 1/6W
2
R66
06051535
RD RESISTOR 15 K-OHM 1/6W
1
R67-69
06051034
RD RESISTOR 10 K-OHM 1/6W
3
C1-3
NOT USED
C4
NOT MOUNTED
C5-8
05052255
CHEM. CAPA. 2.2UF 50V
4
C9
NOT MOUNTED
C10-12
05152212
CERA. CAPA. 220PF 50V
3
C13
05151042
CERA. CAPA. 0.1UF 50V
1
C14
05151033
CERA. CAPA. 0.01UF 50V
1
C15
05152234
CERA. CAPA. 0.022UF 50V
1
C16-17
05152225
CERA. CAPA. 2200PF 50V
2
C18
05152234
CERA. CAPA. 0.022UF 50V
1
C19
*1
05154714
CERA. CAPA. 470PF 50V
1
#1
05152234
CERA. CAPA. 0.022UF 50V
1
C20
05151015
CERA. CAPA. 100PF 50V
1
C21-22
05152212
CERA. CAPA. 220PF 50V
2
C23
NOT USED
C24
05152234
CERA. CAPA. 0.022UF 50V
1
C25
NOT USED
C26
05152234
CERA. CAPA. 0.022UF 50V
1
C27-28
05131044
CERA. CAPA. 0.1UF 25V
2
BC1
05532234
CAPACITOR 0.022UF 25V
1
BC2-3
05152234
CERA. CAPA. 0.022UF 50V
2
BC4
05131044
CERA. CAPA. 0.1UF 25V
1
BC5-6
05152234
CERA. CAPA. 0.022UF 50V
2
BC7
NOT MOUNTED
BC8-10
05152234
CERA. CAPA. 0.022UF 50V
3
TA1-2
*2
07650048
TRANSISTOR ARRAY STA471A=S
2
#2
07650056
TRANSISTOR ARRAY UPA1428AH
2
TR1
07320101
TRANSISTOR 2SD2010
1
TR2
07227853
TRANSISTOR 2SC1740SE
1
TR3
07009502
TRANSISTOR 2SA950
1
TR4-10
NOT USED
TR11
#1
07320101
TRANSISTOR 2SD2010
1
SP216
TR12
NOT USED
TR13
07320101
TRANSISTOR 2SD2010
1
REG1
08202011
IC-REG UPC7824
1
D1-2
08000040
DIODE DSM1D1
2
D3
#1
08000040
DIODE DSM1D1
1
SP216
D4
08000040
DIODE DSM1D1
1
LED1-2
08300136
LED SLZ-390B
2
RA1
06584724
RESIS. ARRAY 4.7K-OHM 1/8W 5EL
1
RA2
06581032
RESIS. ARRAY 10 K-OHM 1/8W 8EL
1
RA3
06581036
RESIS. ARRAY 10 K-OHM 1/8W 5EL
1
RA4-5
06581037
RESIS. ARRAY 10 K-OHM 1/8W 7EL
2
RA6
06581032
RESIS. ARRAY 10 K-OHM 1/8W 8EL
1
RA7
06581023
RESIS. ARRAY 1 K-OHM 1/8W 4EL
1
RA8
06581026
RESIS. ARRAY 1 K-OHM 1/8W 7EL
1
RA9
06581030
RESIS. ARRAY 10 K-OHM 1/8W 3EL
1
