Installing the Drive Unit into the Computer
Preparing a Space for the Drive
1
Remove the screws and brackets securing the floppy disk drive
and the lower drive bay blanking plate.
2
Disconnect the floppy disk drive.
3
Remove the floppy disk drive and the blanking plate.
Floppy disk drive
Lower dirve bay
blanking plate
Remove the screws
and brackets.
Floppy disk drive
Floppy disk drive
Blanking plate
