Do not drop the camera or
subject it to physical shock.
May cause a product malfunction.
Never keep the camera face to
strong light directly.
May damage the CCD.
Do not expose the camera to
radioactivity.
Radioactivity exposure may damage the
CCD.
• Exposure to a spotlight or an object emitting strong light may cause smear or
blooming.
• Ensure that the power source complies with normal specifications before
supplying it to the camera.
Notes
Precautions
Overview
Components and Accessories
❶
7
2
FRONT
❶ Camera Sunshield
2 Sunshield adaptor : Fixing the sunshield onto the camera.
3 Focus lever : Set focus of lens by turn the focus lever.
4 Zoom lever : Set zoom magnification of lens by turn the zoom lever.
5 Front cover
6 Function Setup Switch :
Display the menu on the screen and move the cursor to four directions to confirm
status or after changing a selected item.
7 Video Output Terminal to Monitor :
Used for monitoring of video output When camera installation.
❶ SOC-4160 2 Sunshield 3 L-type hexagon wrenches (3.0mm)
4 Sunshield Adaptor (1EA) 5 Tapping Screw (3EA) ❻ User’s Manual
7 Installation Video Output Cable
