EN-6
SUPPLYING POWER
You can connect the camcorder to an AC outlet
using the AC Power Adapter/Charger (if the
camcorder is supplied with a DC cord).
1 Plug the AC Adapter/Charger’s power cord into
an AC outlet.
2
Connect the AC Adapter to the camcorder.
NOTES:
● Be sure to use the DC cord provided with
your camcorder.
● When using the provided DC cord, make sure
you connect the end of the cable with the
core filter to the camcorder. The core filter
improves performance of equipment.
To AC outlet
AC Power
Adapter/Charger
Power cord
To DC Input
connector
To DC OUT
connector
DC cord
