24
EN
Superimpose
CH 125 RECORD
THU 12:00 AM PAUSE
STEREO ] SP
SAP
INDEX-1
NORM
HI–FI COUNT
–1:23:45
B E + + +
Tuned-in channel or AUX(iliary) mode
When the channel is changed, the new
channel is displayed on the screen for 5
seconds.
Operation mode
When the operation mode is changed,
the new mode is displayed — RECORD
(5 sec.), PLAY (5 sec.), FF/REW (5 sec.
when engaged from Stop mode),
RECORD PAUSE (for as long as Pause is
engaged), and ITR *:** (5 sec.).
INDEX indication
Tape speed indication
"Cassette Loaded" mark
When a cassette is loaded, the mark is
displayed for 5 seconds. It blinks when the
VCR's EJECT button is pushed.
The superimposed indication on the TV screen tells you what the VCR is doing.
Counter reading
This function, switchable between ON and OFF, determines
whether or not operational indicators will appear on screen.
ACCESS MAIN MENU
SCREEN
1
Press MENU.
ACCESS FUNCTION SET
SCREEN
2
Move the highlight bar (arrow) to "FUNCTION SET" by
pressing CH
5∞ or SHUTTLE PLUS%fi, then press OK
or SHUTTLE PLUS .
SELECT SUPERIMPOSE SET
MODE
3
Move the highlight bar
(arrow) to "SUPERIMPOSE"
by pressing CH
5∞ or
SHUTTLE PLUS %fi, then
press OK or SHUTTLE
PLUS to select the
desired mode:
a– Select "ON" if you want
the superimposed
operational indications on the TV screen.
b– Select "OFF" if you do not want the superimposed
operational indications on the screen.
RETURN TO NORMAL
SCREEN
4
Press MENU.
%
Clock time
Tape position indicator
To recall an indication
1 Press OSD.
Ⅲ All indications corresponding to the current status are
displayed for 5 seconds. After that, the counter
information and RECORD/PAUSE if in the Record Pause
mode, are left displayed on the screen.
2 Press OSD again to clear the display.
Ⅲ The RECORD/PAUSE indication is left displayed on
the screen.
CH
MENU OK
PLAYBACK AND RECORDING FEATURES (cont.)
Second Audio Program indication
Stereo program indication
Audio mode indications
1 2 3
4 5
0
6
7 8 9
1
2
4
3
– +
SHUTTLE PLUS
MENU
OK
OSD
FUNCTION
AUTO PICTURE ON
PICTURE CONTROL AUTO
AUTO TIMER OFF
=SUPERIMPOSE ON
AUTO SP =EP TIMER OFF
NEXT PAGE
SELECT WITH ( 5,∞) AND (OK)
PRESS (MENU) TO END
%
NOTES:
● If you engage the Record Pause mode, RECORD/PAUSE is
displayed regardless of the Superimpose mode setting.
● If you select a channel on which no signal is received, the
channel number is displayed regardless of the Superimpose
mode setting.
