Connecting to a TV
Connecting the player to a TV equipped with an HDMI input jack
Note • To get the best possible image quality, we recommend using a Category 2 (high speed) HDMI cable.
Connecting the player to a TV equipped with AV input jacks
Player rear panel
TV
HDMI input
HDMI cable (optional)
TV
A/V cable (supplied)
Video input
Audio input (left)
Audio input (right)
Video input
Player rear panel
Using the A/V cable
connect to the TV.
White
Red Yellow
AC Outlet
Wider Hole
and Blade
AC Outlet
Wider Hole
and Blade
6
