Digital Still Camera Function
(GR-DVL1020/DVL820/DVL520 only)
Storage media : SD Memory Card/MultiMediaCard
Compression system : Still image : JPEG (compatible)
Moving image* : MPEG4 (compatible)
File size : 3 modes (1280 X 960 pixels*, 1024 x 768 pixels, 640 x 480 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of
storable images :
੬
pg. 27.
* GR-DVL1020/DVL820 only.
Connectors
S-Video
Output : Y:1 V (p-p), 75
Ω
, analogue
C:0.29 V (p-p), 75
Ω
, analogue
Input (GR-DVL1020/DVL820 only) : Y:0.8 V (p-p) – 1.2 V (p-p), 75
Ω
, analogue
C:0.2 V (p-p) – 0.4 V (p-p), 75
Ω
, analogue
AV
Video output : 1 V (p-p), 75
Ω
, analogue
Video input (GR-DVL1020/DVL820 only) : 0.8 V (p-p) – 1.2 V (p-p), 75
Ω
, analogue
Audio output : 300 mV (rms), 1 k
Ω
, analogue, stereo
Audio input (GR-DVL1020/DVL820 only) : 300 mV (rms), 50 k
Ω
, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
Input : 4-pin, IEEE 1394 compliant
USB (GR-DVL1020/DVL820/DVL520 only) : 5-pin
PC (GR-DVL320 only) : ø2.5 mm, 3-pole
EDIT (GR-DVL1020/DVL820/DVL520 only) : ø3.5 mm, 2-pole
JLIP (GR-DVL320 only) : ø3.5 mm, 4-pole
AC Adapter
Power requirement : AC 110 V to 240 V ` , 50 Hz/60 Hz
Output : DC 11 V , 1 A
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications
subject to change without notice.
