JVC Compact VHS - Manual (Page 40)

EN
41
Controls
1 Power Zoom Button ...........................
੬
pg. 14
2 Select Dial .........................................
੬
pg. 18
3 Multi-Function Control
•EFFECT Button .................................
੬
pg. 20
•WIDE Button ...................................
੬
pg. 20
•TITLE Button ....................................
੬
pg. 21
•SUPER LOLUX Button .....................
੬
pg. 21
4 PUSH Button ......................................
੬
pg. 9
5 Recording Mode [SP/LP] Button .........
੬
pg. 8
6 DATE/TIME Button .............................
੬
pg. 17
COUNTER R/M Button .......................
੬
pg. 34
7 5SEC. REC [5-sec recording] Button ...
੬
pg. 15
8 REW Button .......................................
੬
pg. 32
RETAKE R [Quick Review] Button ......
੬
pg. 15
9 PLAY/PAUSE Button ...........................
੬
pg. 32
0 FF Button ...........................................
੬
pg. 32
RETAKE F Button ................................
੬
pg. 15
! STOP Button ......................................
੬
pg. 32
@ EJECT Switch ......................................
੬
pg. 9
# Function Navigator Dial
[MENU Jog Dial] ................................
੬
pg. 7
$ LIGHT OFF/AUTO/ON Switch ...........
੬
pg. 16
% BATT. [Battery] RELEASE Switch .........
੬
pg. 4
^ Dioptre Adjustment ............................
੬
pg. 10
& Recording Start/Stop Button ................
੬
pg. 12
* Power Switch ................................
੬
pg.12, 32
( LENS COVER Switch ..........................
੬
pg. 12
Connectors
) DC IN Jack .........................................
੬
pg. 5
The jacks q to r are located beneath the jack
cover.
q J terminal [JLIP (Joint Level Interface Protocol)
Connector.]
• It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
• JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with
a J terminal.
w VIDEO OUT Connector .....................
੬
pg. 36
e RF DC OUT Connector ......................
੬
pg. 36
r AUDIO OUT Connector ....................
੬
pg. 36
Indicators
t Power Indicator ..................................
੬
pg. 12
y Tally Lamp .........................................
੬
pg. 12
Other Parts
u Video Light .........................................
੬
pg. 16
i Microphone
o Camera sensor
Be careful not to cover this area; built-in
here is the sensor necessary for shooting.
p Clock Battery Compartment ...............
੬
pg. 6
Q Battery Pack Mount ............................
੬
pg. 4
W Shoulder Strap Eyelets ........................
੬
pg. 11
E Electronic Viewfinder .........................
੬
pg. 10
R Grip Strap ..........................................
੬
pg. 10
T Tripod Mounting Socket .....................
੬
pg. 11
