Chapter 2—Functional Descriptions
2-30 Model 330. 340SC, and 370SC Service Manual
Bus I/O Information Description
IIC I Serial data load Command to the serial data receiver that the
incoming data is to be read.
Serial I HPHASE Commanded horizontal phase of picture.
Serial I HLINR Commanded amount of overall H linearity
correction.
Serial I TBKEY Commanded amount of top and bottom Keystone
Correction.
Serial I HCENTBLU Commanded horizontal position of blue raster.
Serial I HCENTGRN Commanded horizontal position of green raster.
Serial I HCENTRED Commanded horizontal position of red raster
Serial I WIDTH Commanded width of raster
Horizontal Deflection Board I/O
This section provides a description of the inputs to and outputs from the HDB. The I/O
description are arranged by the source/destination of the signal and so the assemblies
communicated with are used as the primary heading of each group of signals and then are
further subdivided into inputs and outputs. In each case, the signal's direction is noted,
with input referring to an input to the RTG, and output to an output from the HDB. (e.g.:
under Raster Timing Generator 'Input'; /VFBST refers to the signal /VFBST that is an
input to the HDB from the Raster Timing Generator). When test points are provided for
the I/O they are noted.
Table 2-7 Horizontal Deflection Board I/O Signals
System Controller Board
Inputs Description
IICCLK IIC clock line. Unidirectional clock line for control of synchronous data
transfer over IIC data bus.
+SERCLK Serial data transfer clock (+). Unidirectional, differential clock line from
SCB to other circuit boards. Used for synchronous control of serial
communication over SERDATA data lines.
-SERCLK Serial data transfer clock (-).
System Controller Board
Inputs Description
+SERDATA Serial data transfer. Unidirectional, differential, synchronous serial data
communication line. Used for transferring data from SCB to other
circuit boards. Uses SERCLK and IIC for control of receiver.
-SERDATA Serial data transfer
Outputs Description
/IICINT IIC interrupt line. Signal line for slave boards to inform the SCB (master)
that there is data to be transferred. Master then polls slaves to
determine the source of the interrupt.
I/O Description
