CONNECTING AND TROUBLESHOOTING
CONNECTING DV DEVICE
1 Plug the included DV cable’s larger
connector into the socket on the DV
Capture Board.
• Confirm that the connector is securely
plugged in.
2 Plug the DV cable’s smaller connector
into the camcorder’s DV OUT/IN socket.
• Confirm that the connector is securely
plugged in.
• Refer to your camcorders’s instruction
book to locate the camcorder’s DV
OUT/IN socket.
DV IN/OUT
