Ancillaries
Ancillaries
HORN
SWITCHES
CASSETTE
CASSETTE
STEERING WHEEL
CAUTION: The Steering Wheel contains two logic
ground circuits that must remain separate. Do not
connect or cross-switch the BO and BK circuits.
HORNS
HORN
CONTROL
BODY PROCESSOR MODULE
HORN RELAY (#6) †
ENGINE COMPARTMENT FUSE BOX
RH HORN
LH HORN
CIGAR LIGHTER
CIGAR LIGHTER
ACCESSORY CONNECTOR RELAY (#6)
TRUNK FUSE BOX
TRUNK
ACCESSORY
CONNECTOR
FASCIA
ACCESSORY
CONNECTOR
NOTE: BT2BR – Adaptive Damping vehicles only.
ACCESSORY CONNECTORS
GARAGE DOOR
OPENER
ROOF CONSOLE
GARAGE DOOR OPENER
† NOTE: Early production vehicles (
➞
VIN 003300) have connector pin
numbers that differ from the volume production pin numbers shown.
Use the wire color code for pin identification on early production vehicles.
VARIANT:
All Vehicles
VIN RANGE:
All
DATE OF ISSUE:
OCTOBER 1996
POWER
LOGIC
