Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
For Connectors
S
S-Video input
(GR-DV700/500 only)
:
Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
C: 0.2 V to 0.4 V (p-p), 75 Ω, analogue
S-Video output
:
Y: 1.0 V (p-p), 75 Ω, analogue
C: 0.29 V (p-p), 75 Ω, analogue
AV
Video input
(GR-DV700/500 only)
:
Y: 0.8 V to 1.2 V (p-p), 75 Ω, analogue
Video output
:
Y: 1.0 V (p-p), 75 Ω, analogue
Audio input
(GR-DV700/500 only)
:
300 mV (rms), 50 kΩ, analogue, stereo
Audio output
:
300 mV (rms), 1 kΩ, analogue, stereo
EDIT
:
ø3.5 mm, 2-pole
Headphone output
:
Stereo
DV
Input/output
(GR-DV700/500 only)
:
4-pin, IEEE 1394 compliant
Output
(GR-DV600/400 only)
:
4-pin, IEEE 1394 compliant
USB
:
5-pin
AC Adapter
For General
Power requirement
:
AC 110 V to 240 Vd, 50 Hz/60 Hz
Output
:
DC 11 V G, 1 A
