Engine 210LE
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . John Deere 4045D, naturally aspirated standard / John Deere 4045T, turbocharged optional; meets EPA and CARB emission non-road regulations
Rated power @ 2,200 rpm . . . . . . . . . . . . . . . . . . . . . . . . . 78 SAE gross hp (58.2 kW) / 73 SAE net hp (54.4 kW)
John Deere 4045T with turbocharger . . . . . . . . . . . . . 84.5 SAE gross hp (63 kW) / 80 SAE net hp (60 kW)
Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276 cu. in. (4.524 L)
Fuel consumption, typical . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1 to 1.9 gal./hr. (4.2 to 7.2 L/h)
Torque rise, net. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 percent
Maximum net torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220 lb.-ft. (298 Nm)
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pressure system with spin-on filter and cooler
Air cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . dual stage dry type with safety element, evacuator valve, and prescreener
Electrical system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 volt with 65-amp alternator
Cooling fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . sucker type, 1:1 speed ratio
Transmission
Four-speed, helical-cut gear, collar-shift transmission synchronized in all gears with hydraulic reverser (optional full-power-shifted transmission)
Torque converter, single stage, dual phase with 2.63:1
stall ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 in. (280 mm) diameter
Travel speeds (maximum) with 16.9-24, 8 PR R4 rear
and 12-16.5, 8 PR NHS front tires Forward Reverse
Gear 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6 mph (5.8 km/h) 4.0 mph (6.4 km/h)
Powershift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6 mph (5.8 km/h) 4.0 mph (6.4 km/h)
Gear 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.9 mph (9.5 km/h) 6.6 mph (10.6 km/h)
Powershift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.8 mph (9.3 km/h) 6.7 mph (10.8 km/h)
Gear 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.9 mph (22.4 km/h) 13.9 mph (22.4 km/h)
Powershift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13.9 mph (22.4 km/h) 16.1 mph (25.9 km/h)
Gear 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20.5 mph (33.0 km/h) 20.5 mph (33.0 km/h)
Powershift. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20.5 mph (33.0 km/h) N/A
Final Drives
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . heavy-duty, inboard planetary final drives evenly distribute shock loads over three gears
Brakes (conform to SAE J1473)
Service brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . hydraulic multi wet disc, mounted inboard, self adjusting and self equalizing
Parking and secondary brake . . . . . . . . . . . . . . . . . . . . . . . spring applied, hydraulically released multi wet disc, independent of service brakes, switch-operated electrical control, self engaging with engine shutdown
Capacities
Fill / Change
Fuel tank (with ground level fueling). . . . . . . . . . . . . . . . . . 26 gal. (98 L)
Engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.3 gal. (16 L)
Engine oil including filter . . . . . . . . . . . . . . . . . . . . . . . . . . 9 qt. (8.5 L)
Torque converter and transmission. . . . . . . . . . . . . . . . . . . 15 qt. (14 L)
Hydraulic system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14.4 gal. (54.5 L)
Rear axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 gal. (13 L)
Mechanical-front-wheel-drive axle . . . . . . . . . . . . . . . . . . . 2.3 gal. (8.5 L)
Steering
Type hydrostatic power steering conforms to SAE J1151, emergency steering to SAE J53
Mechanical-front-wheel-drive
Curb turning radius with brakes . . . . . . . . . . . . . . . . . 10 ft. 11 in. (3.34 m)
Without brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 13 ft. 8 in. (4.17 m)
Bucket clearance circle with brakes . . . . . . . . . . . . . . 29 ft. 9 in. (9.07 m)
Without brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 35 ft. 3 in. (10.74 m)
Steering wheel turns, stop to stop. . . . . . . . . . . . . . . . 3
Axle oscillations stop to stop, both axles. . . . . . . . . . . . . . . 22 degrees
Axle ratings (SAE J43) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17,340 lb. (7865 kg) front / 12,610 lb. (5720 kg) rear
Hydraulic System
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . open center
Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2,750 psi (19 000 kPa)
Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . gear type with integral priority valve
Flow @ 2,200 rpm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 gpm (94.5 L/min.)
Filter, return oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-micron, spin-on enclosed replaceable element
Cylinders
Bore Stroke Rod
Loader boom (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.15 in. (80 mm) 31.1 in. (790 mm) 1.97 in. (50 mm)
Loader bucket (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.54 in. (90 mm) 29.3 in. (744 mm) 1.97 in. (50 mm)
Steering (1) standard axle. . . . . . . . . . . . . . . . . . . . . . . . . . 1.97 in. (50 mm) 9.49 in. (241 mm) 0.98 in. (25 mm)
Steering (1) MFWD axle . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.56 in. (65 mm) 8.27 in. (210 mm) 1.42 in. (36 mm)
