English
58
FM tuner (IHF)
Tuning Range: 87.5 MHz to 108.0 MHz
Usable Sensitivity: Monaural: 12.8 dBf (1.2 µV/75
Ω
)
50 dB Quieting Sensitivity: Monaural: 21.3 dBf (3.2 µV/75
Ω
)
Stereo: 41.3 dBf (31.5 µV/75
Ω
)
Signal-to-Noise Ratio (IHF-A weighted): Monaural: 78 dB at 85 dBf
Stereo: 73 dB at 85 dBf
Total Harmonic Distortion: Monaural: 0.4% at 1 kHz
Stereo: 0.6% at 1 kHz
Stereo Separation at REC OUT: 35 dB at 1 kHz
Alternate Channel Selectivity: 45 dB: (±400 kHz)
Frequency Response: 30 Hz to 15 kHz: (+0.5 dB, –3 dB)
AM tuner
Tuning Range: 530 kHz to 1 710 kHz
Usable Sensitivity: Loop antenna 400 µV/m
Signal-to-Noise Ratio: 50 dB (100 mV/m)
General
Power Requirements: AC 120V , 60 Hz
Power Consumption: 320 W/440 VA (at operation)
2 W (in standby mode)
Dimensions (W × H × D): 435 mm × 156.5 mm × 425 mm
(17 3 / 16 in.
×
6 3 / 16 in.
×
16 3 / 4 in.)
Mass: 11.5 kg (25.4 lbs)
Designs & specifications are subject to change without notice.
