Specifi cations
General
Model name DT-R24L4D DT-R17L4D
Type Multi format LCD monitor
Screen size Type 24 wide format Type 17 wide format
Aspect ratio 16:10 16:9
Horizontal/vertical frequency
(computer signal) H: 31.469 kHz – 75.000 kHz
V: 48 Hz – 65 Hz
* Some signals within this frequency range may not be displayed (“Out of range” is displayed).
Compliant video signal format ☞ “Available signals” on page 26
Format HD SDI: BTA S-004C, SMPTE292M
SD SDI: ITU-R BT.656: 525/625
SMPTE259M:
525
EMBEDDED AUDIO:
SMPTE299M,
SMPTE272M
Audio output Internal speaker: 1.0 W + 1.0 W
Operating conditions Operating temperature: 5°C – 35°C (41°F – 95°F)
Operating humidity: 20% – 80% (non-condensing)
(Slightly variable depending on ambient conditions for installation.)
Power requirements AC 120 V/AC 220 – 240 V, 50 Hz/60 Hz
Rated current 1.15 A (AC 120 V)
0.67 A (AC 220 – 240 V) 1.2 A (AC 120 V)
0.8 A (AC 220 – 240 V)
External dimensions
(excluding protruding parts) Width:
564 mm (22 1/4˝)
564 mm (22 1/4˝)
Height:
413.1 mm (16 3/8˝)
408 mm (16 1/8˝)
Depth:
181 mm (7 1/4˝)
99 mm (4˝)
(with the stand) (without the stand)
Width:
430 mm (17˝)
430 mm (17˝)
Height:
314.1 mm (12 3/8˝)
309 mm (12 1/4˝)
Depth:
181 mm (7 1/4˝)
102 mm (4 1/8˝)
(with the stand) (without the stand)
Weight 10.1 kg (22.2 lbs) (with the stand)
8.6 kg (18.9 lbs) (without the stand) 8.0 kg (17.6 lbs) (with the stand)
6.5 kg (14.3 lbs) (without the stand)
Accessories AC power cord, Power cord holder x 1, Screw x 2 (for power cord holder)
LCD panel
Model name DT-R24L4D DT-R17L4D
Type 24˝ wide, active matrix TFT 17˝ wide, active matrix TFT
Effective screen size Width: 518.4 mm (20 1/2˝)
Height: 324 mm (12 7/8˝)
Width: 372.9 mm (14 3/4˝)
Height: 209.7 mm (8 3/8˝)
Number of pixels displayed 1 920 x 1 200 1 366 x 768
Number of colors displayed 16.77 million
Viewing angle (TYP.) 178° (Horizontally), 178° (Vertically) 178° (Horizontally), 178° (Vertically)
Brightness (TYP.) 400 cd/m 2 350 cd/m 2
Contrast ratio (TYP.) 1000:1 900:1
Input/output terminals
Model name DT-R24L4D DT-R17L4D
Video
VIDEO (INPUT 1)
Input/output of composite signal:
2 line, BNC connector x 4,
1 V(p-p), 75 Ω
VIDEO
Input/output of composite signal:
1 line, BNC connector x 2,
1 V(p-p), 75 Ω
VIDEO (INPUT 2)
* The input (IN) and output (OUT)
terminals are bridge-connected (auto
termination). * The input (IN) and output (OUT)
terminals are bridge-connected (auto
termination).
DVI-D (HDCP)
DVI-D signal input (compatible with HDCP):
DVI-D connector x 1 (compatible with DDC2B)
E. AUDIO HD/SD SDI (IN 1) Digital signal input (compatible with EMBEDDED AUDIO signals):
auto detection, 2 line, BNC connector x 2 E. AUDIO HD/SD SDI (IN 2)
E. AUDIO HD/SD SDI
(SWITCHED OUT)
Digital signal output (compatible with EMBEDDED AUDIO signals):
1 line switched out, BNC connector x 1
Audio
AUDIO ASSIGN (IN 1) Analog audio signal input:
2 line, RCA connector x 4,
500 mV (rms), high impedance
AUDIO (IN)
Analog audio signal input:
1 line, RCA connector x 2,
500 mV (rms), high impedance
AUDIO ASSIGN (IN 2)
AUDIO ASSIGN
(MONITOR OUT)
Analog audio signal output:
1 line, RCA connector x 2,
500 mV (rms)
AUDIO
(MONITOR OUT)
Analog audio signal output:
1 line, RCA connector x 2,
500 mV (rms)
External
control
REMOTE (MAKE/TRIGGER) ☞ “Using the MAKE/TRIGGER system” on page 18
REMOTE (RS-485)
☞ “Using the serial communication” on page 20
REMOTE (RS-232C)
„
„
„
