42
English
Operating JVC’s Audio/Video Components
You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC
components are preset in the remote control.
IMPORTANT:
To operate JVC’s audio components using this remote control:
• You need to connect JVC audio components through the COMPU
LINK-3 (SYNCHRO) jacks (see page 36) in addition to the
connections using cables with RCA pin plugs (see pages 5 and 6).
• Aim the remote control directly at the remote sensor on the receiver.
• If you use the buttons on the front panel or the menu function to
choose a source, the remote control will not operate that source. To
operate a source with the remote control, the source must be
selected using source selecting buttons on the remote control.
• To operate the cassette deck or MD recorder using the COMPU
LINK remote control system, set the source name correctly. (See
page 12.)
• Refer also to the manuals supplied with your components.
Sound control section (Amplifier)
You can always perform the following operations (with the remote
control mode selector set to “AUDIO/TV/VCR”):
SURROUND ON/OFF : Turns on or off the Surround modes —
Dolby Pro Logic, Dolby Digital, DTS
Digital Surround, and MPEG Multichannel.
SURROUND MODE : Selects the DSP modes.
After pressing SOUND (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations:
SEA MODE : Changes the SEA modes.
SUBWOOFER – / + : Adjusts the subwoofer output level.
CNTR – / + : Adjusts the center speaker output level.
REAR•L – / + : Adjusts the left rear speaker output level.
REAR•R – / + : Adjusts the right rear speaker output level.
EFFECT : Selects the effect level.
TEST : Turns on or off the test tone output.
CNTR TONE : Selects the center tone.
Note:
After adjusting sounds, press the corresponding source selecting
button or DISC to operate your target source by using the 10 keys;
otherwise, the 10 keys cannot be used for operating your target
source.
CD player
After pressing CD (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations on
the CD player:
PLAY : Starts playing.
4 4 4 4 4:
Returns to the beginning of the current (or
previous) track.
¢ ¢ ¢ ¢ ¢:
Skips to the beginning of the next track.
STOP : Stops playing.
PAUSE : Pauses playing. To release it, press PLAY.
1 – 10, +10 : Selects a track number directly.
For track number 5, press 5.
For track number 15, press +10, then 5.
For track number 20, press +10, then 10.
For track number 30, press +10, +10, then 10.
CD player-changer
After pressing DISC (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations on a
CD player-changer:
PLAY : Starts playing.
4 4 4 4 4: Returns to the beginning of the current (or previous)
track.
¢ ¢ ¢ ¢ ¢: Skips to the beginning of the next track.
STOP : Stops playing.
PAUSE : Pauses playing. To release it, press PLAY.
1 – 6, 7/P : Selects the number of a disc installed in a CD
player-changer.
After pressing CD (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations on
the CD player-changer:
1 – 10, +10 : Selects a track number directly.
For track number 5, press 5.
For track number 15, press +10, then 5.
For track number 20, press +10, then 10.
For track number 30, press +10, +10, then 10.
RM-SRX889P REMOTE CONTROL
CONTROL
CHANNEL VOLUME TV VOL
STOP PAUSE
FF/ /REW
VCR 1 TV/VIDEO TAPE MUTING
REC
PLAY
TV/CATV/DBS VCR 1
DVD DVD MUILTI CD TAPE/MD
TV/DBS VIDEO PHONO FM/AM
VCR 1 VCR 2 ANALOG/DIGITAL
SURROUND CNTR TONE CNTR
SURROUND TEST REAR-L
DISC
MODE
ON/OFF
EFFECT REAR-R
SOUND SEA MODE SUBWOOFER
RETURN
SET
MENU
AUDIO/
TV/VCR
EXIT TEXT
DISPLAY
FM MODE/MUTING
SLEEP
1 2 3
4 5 6
7 /P 8 9
10 0 +10
100+
CATV/DBS
MENU MENU
ENTER ENTER
AUDIO/
TV/VCR
CATV/DBS
TUNING DOWN UP
Check to see if its remote
control mode selector is set
to the correct position.
To operate the audio
system, TVs, and VCRs,
set it to “AUDIO/TV/VCR.”
Tuner
After pressing FM/AM (with the remote control mode selector set to
“AUDIO/TV/VCR”), you can perform the following operations:
FM/AM : Alternates between FM and AM.
1 – 10, +10 : Selects a preset channel number directly.
For channel number 5, press 5.
For channel number 15, press +10, then 5.
For channel number 20, press +10, then 10.
TUNING UP/TUNING DOWN :
Tunes into stations.
FM MODE/MUTING : Changes the FM reception mode.
