7
English
DVD player
• When you connect the DVD player with stereo output jacks:
DVD player
Å To front left/right channel audio output (or to audio mixed
output if necessary)
ı To S-video output
Ç To composite video output
DVD
VIDEO
VIDEO S-VIDEO RIGHT LEFT AUDIO
DVD
A B C
DVD
VIDEO
VIDEO S-VIDEO RIGHT LEFT AUDIO
MONITOR
OUT
VCR 1
IN
(PLAY)
OUT
(REC)
IN
(PLAY)
OUT
(REC)
TV SOUND
/DBS
DVD
VCR 2 DVD
CENTER
SUB
WOOFER
A
E D
B C
F
• When you connect the DVD player with its analog discrete output
(5.1 CH reproduction) jacks:
Å To center channel audio output
ı To subwoofer audio output
Ç To S-video output
Î To front left/right channel audio output
‰ To rear left/right channel audio output
Ï To composite video output
DVD player
Video camera
The VIDEO jacks on the front panel is convenient when connecting
and disconnecting the equipment frequently.
VIDEO
S-VIDEO VIDEO AUDIO L R
To composite
video output
To S-video output
To audio
output
Note:
When connecting the DBS tuner to the TV SOUND/DBS jacks,
change the source name, which will be shown on the display when
selected as the source, to “DBS.” See page 12 for details.
DBS
RIGHT
VIDEO
VIDEO S-VIDEO RIGHT LEFT AUDIO
IN
(PLAY)
OUT
(REC)
IN
(PLAY)
OUT
(REC)
TV SOUND
/DBS
DVD
VCR 2
DBS tuner
To audio
output
To composite video output
To S-video output
Notes:
• Use a TV of the PAL- or multi-color system.
• When connecting the TV to the TV SOUND/DBS jacks, DO NOT
connect the TV’s video output to these video input terminals.
RIGHT
VIDEO
VIDEO S-VIDEO RIGHT LEFT AUDIO
MONITOR
OUT
VCR 1
IN
(PLAY)
OUT
(REC)
IN
(PLAY)
OUT
(REC)
TV SOUND
/DBS
DVD
VCR 2
TV and/or DBS tuner
To audio
output
TV
Connect the TV to the MONITOR
OUT jack to view the playback
picture from the other connected
video components.
To composite video input
To S-video input
