Ordering information
Switch fabric Options
fEaturE E120 OPtiOnS E320 OPtiOnS
Switch fabric capacity 120 Gbps 100 Gbps or 320 Gbps
Switch fabric modules SFM-120
SFM-320*
SFM-100
SFM-320
Switch route processor
modules
SRP-120
SRP-320*
SRP-100
SRP-320
line Module Options
linE MOdulE Part nuMBEr dEScriPtiOn
4 Gbps line Module ES2 4G LM 4 Gbps processing
capacity for all I/O
adapter types
10 Gbps line Modules ES2 10G-U LM
ES2 10G-A LM
• 10 Gbps processing
for 10-Gigabit
Ethernet I/O adapter
only
• 10 Gbps processing
for Gigabit Ethernet
and 10-Gigabit
Ethernet I/O adapters
density Maximums
tEcHnOlOGy Part nuMBEr dEScriPtiOn Max
POrtS,
E120
Max
POrtS,
E320
10-Gigabit
Ethernet
120 ES2-S1 10GE
IOA
1x10-Gigabit
Ethernet
6 12
Gigabit
Ethernet
ES2-S1 GE-4 IOA
ES2-S1 GE-8 IOA
4xGigabit
Ethernet
8x Gigabit
Ethernet
24
96
48
192
Oc3/StM1 ES2-S1 OC3-8/
STM1 IOA
8xOC3/STM1
(ATM only)
96 192
Oc12/StM4 ES2-S1 OC12-2/
STM4 IOA
2xOC12/STM4
(ATM/POS)
24 48
Oc48/StM16 ES2-S1 OC48-2/
STM16 IOA
1xOC48/STM16
(POS)
6 12
* The E120 supports a maximum of 120 Gbps capacity per system, independent of the SFM and
SRP used.
MOdEl nuMBEr MOdEl naME and dEScriPtiOn
E320 and E120 Base System Options
ES2-BSlM6-SyS 6-slot E120 chassis
ES2-BSlM12-SyS 12-slot E320 chassis
E320 and E120 SfM and SrP Options
ES2-100G-SfM 100 G SFM for the E320 only.
ES2-100G-SrP 100 G SRP for the E320 only.
ES2-120G-SfM 120 G SFM for the E120 only.
ES2-120G-SrP 120 G SRP for the E120 only.
ES2-320G-SfM 320 G SFM; supported in the E320 and E120.
ES2-320G-SrP 320 G SRP; supported in the E320 and E120.
E320 and E120 lM Options
ES2-10GacS3-MOd 10 G access line module (LM10A)
ES2-10GuPS2-MOd 10 G uplink line module (LM10U)
ES2-4GS1-MOd 4 G line module (LM4)
E320 and E120 Service Module
ES2-SErvS1-iOa Supports highly scalable L2TP LNS and GRE
tunnels, as well as Network Address Translation
(NAT) and Firewall Services.
E320 and E120 iOa Options
ES2-10GES1-iOa Provides a single 10 Gigabit Ethernet port via an
XFP interface.
ES2-10GES2-iOa Provides two 10 Gigabit Ethernet ports (1-active,
1-standby) via XFP interfaces.
ES2-2Oc12aS1-iOa Provides two OC12/STM4 ATM ports via SFP
interfaces in a half-slot form factor.
ES2-2Oc12PS1-iOa Provides two OC12/STM4 POS ports via SFP
interfaces in a half-slot form factor.
ES2-8Oc3aS1-iOa Provides eight OC3/STM1 ATM ports via SFP
interfaces in a half-slot form factor.
ES2-GE20S3-iOa Provides 20 Gigabit Ethernet ports via SFP
interfaces in a half-slot form factor.
ES2-GE8S1-iOa Provides eight Gigabit Ethernet ports via SFP
interfaces in a half-slot form factor.
ES2-Oc48PS1-iOa Provides a single OC48/STM16 POS port via SFP
interfaces in a half-slot form factor.
ES2-GE4S1-iOa Provides four Gigabit Ethernet ports via SFP
interfaces.
Performance-Enabling Services and Support
Juniper Networks is the leader in performance-enabling services and support, which are designed to accelerate, extend, and optimize
your high-performance network. Our services allow you to bring revenue-generating capabilities online faster so you can realize bigger
productivity gains, faster rollouts of new business models and ventures, and greater market reach, while generating higher levels of
customer satisfaction. At the same time, Juniper Networks ensures operational excellence by optimizing your network to maintain
required levels of performance, reliability, and availability. For more details, please visit www.juniper.net/products-services.
