84
HD-ILA Device Projection Type
Reception Format
Reception Range
Power Source
Power Consumption
Model
NTSC, BTSC System (Multi-Channel Sound)
ATSC Terrestrial, Digital Cable
AC 120V, 60 Hz
219W
120W High-Pressure Mercury Lamp
Screen Size
Speakers
Audio Output Full Range - 10W + 10W + 10W
Antenna Terminal
(VHF/UHF,
ATSC/DIGITAL
CABLE IN)
75 ohms (VHF/UHF)(F-type connector)
Input 3, 4, 5
Terminal
S (Input 3)
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance
Input 3, 4 Terminal
(component terminal)
1080i / 720p / 480p / 480i
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
P
B /P R : 0.7 Vp-p 75 ohms
Input 1, 2 Terminal
(HDMI Input Terminal)
Video: 1080p / 1080i / 720p / 480p / 480i / VGA
Audio: 2ch PCM, 32 / 44.1 / 48 KHz 16 / 20 / 24 bit
• Personal computer compatibility cannot be guaranteed.
Illuminated remote control unit x 1 / AA batteries X 2
Front Pedestal x 1 / Rear Pedestal x 1
Philips type screws x 14
Dimensions (inch)
W X H X D (cm)
Weight (lbs / kg)
Accessories
Audio Output Jacks
(FIX)
FIX : 500mVrms (-4dBs) Low impedance (1000 Hz when modulated 100%)
Projection Source
Optical Output
Digital Audio
Digital Out (optical) x 1
Input 5 Terminal
(PC Input Terminal)
Analog RGB D-SUB (15 pin) x 1
• PC signal is available. Refer to page 24 for details on the signals which
can be input.
58 inch / 147 cm
measured diagonally,
16:9 ratio
51 1/2 x 37 7/8 x 13 5/8
130.5 x 96.1 x 34.6
(With Pedestals)
51 1/2 x 37 7/8 x 10 3/4
130.5 x 96.1 x 27.2
(Without Pedestals)
118.8 / 54 (With Pedestals)
114.7 / 52 (Without Pedestals)
HD-58S998
VHF 2 to 13, UHF 14 to 69 CATV 125 Sub, Mid, Super, Hyper
and Ultra bands (181 channel frequency synthesizer system) at Analog
• Reception of channel A-5 ("95" of the TV set's on-screen cable channel
numbers) is not recommended for your TV set.
VHF 2 to 13, UHF 14 to 69 at ATSC,
CATV 125 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable
(1 cm x 9.5 cm) x 2, 10 cm round x 1
65 inch / 165 cm
measured diagonally,
16:9 ratio
HD-65S998
57 1/2 x 41 9/16 x 14 9/16
145.9 x 105.5 x 36.9
(With Pedestals)
57 1/2 x 41 9/16 x 11 5/8
145.9 x 105.5 x 29.5
(Without Pedestals)
145.2 / 66 (With Pedestals)
140.8 / 64 (Without Pedestals)
Specifications
Specifications subject to change without notice.
• The open source software is embedded in this product. For more information, please go to:
http://software.jvc.com/opensource/lnx/DP/05_AtscQam/download.html
