33
XL-PM25SL / LVT0997-005A / [E]
Using with an au-
dio system
You can use an audio system by connecting it to the unit
with a stereo connection cable (not supplied).
• Connect the cable to the amplifier after turning off its
power.
• Do not connect the cable to the PHONO jacks on the
amplifier.
• Obtain the optional connecting cable if the amplifier
comes with mini-phone jacks.
• Adjust the volume level on the amplifier.
LINE OUT jack
Stereo connection cable (not supplied)
Amplifier
(White)
(Red)
Note:
To obtain original sound, set HBS to OFF. Also, set the
sound effect to “FLAT”. (see page 27)
a
b
c
d
e
”
