Engine
17
ZTS
27C
ZTS
35C
ZTS
50C
ZTS
Make. . . . . . . . . . . . . . . . . . . . . . . . . Isuzu
Isuzu
Isuzu
Isuzu
Model . . . . . . . . . . . . . . . . . . . . . . . . 3YB1
3LD2
3LD2
4LE2
Fuel. . . . . . . . . . . . . . . . . . . . . . . . . . Diesel
Diesel
Diesel
Diesel
Cooling . . . . . . . . . . . . . . . . . . . . . . . Liquid
Liquid
Liquid
Liquid
Displacement . . . . . . . . . . . . . . . . . . 46.4 cu. in. (0.76 L)
91.5 cu. in. (1.50 L)
91.5 cu. in. (1.50 L)
133.0 cu. in. (2.18 L)
Horsepower. . . . . . . . . . . . . . . . . . . . 12.3 hp (9.2 kW) @ 2,300 rpm
32.0 hp (23.5 kW) @ 2,450 rpm
32.0 hp (23.5 kW) @ 2,450 rpm
41.5 hp (30.5 kW) @ 2,200 rpm
Performance
Operating Weight . . . . . . . . . . . . . . . .3,814 lb. (1730 kg)
6,482 lb. (2940 kg)
7,760 lb. (3520 kg)
10,252 lb. (4650 kg)
Maximum Travel Speed
Low . . . . . . . . . . . . . . . . . . . . . . .1.2 mph (2.0 km/h)
1.5 mph (2.4 km/h)
2.0 mph (3.2 km/h)
1.6 mph (2.5 km/h)
High . . . . . . . . . . . . . . . . . . . . . .2.5 mph (4.0 km/h)
2.5 mph (4.0 km/h)
2.8 mph (4.5 km/h)
2.7 mph (4.4 km/h)
Hydraulic Pumps . . . . . . . . . . . . . . . .3 total
3 total
3 total
1 total
Type . . . . . . . . . . . . . . . . . . . . . .2 piston and 1 gear
2 piston and 1 gear
2 piston and 1 gear
1 piston
Total Capacity
Piston . . . . . . . . . . . . . . . . . .4.4 gpm (16.8 L/min.) x 2
8.2 gpm (31.0 L/min.) x 2
10.8 gpm (40.8 L/min.) x 2
29.1 gpm (110.0 L/min.)
Gear . . . . . . . . . . . . . . . . . . .3.3 gpm (12.5 L/min.)
4.4 gpm (16.8 L/min.)
7.1 gpm (26.8 L/min.)
N/A
Auxiliary Flow . . . . . . . . . . . . . . .7.7 gpm (29.3 L/min.)
12.6 gpm (47.8 L/min.)
17.9 gpm (67.6 L/min.)
22.5 gpm (85.2 L/min.)
Fuel Tank Capacity . . . . . . . . . . . . . .6.6 gal. (25 L)
10.5 gal. (40 L)
10.5 gal. (40 L)
13.2 gal. (50 L)
Hydraulic Tank Capacity . . . . . . . . . .7.4 gal. (28 L)
7.9 gal. (30 L)
7.9 gal. (30 L)
11.8 gal. (45 L)
Ground Pressure (With Rubber Track) . . .29.9 kPa (4.34 psi)
26.0 kPa (3.80 psi)
30.0 kPa (4.40 psi)
26.0 kPa (3.80 psi)
Lift Capacities
Ground Level at 10-ft. (3.05 m)
Radius
Over Front, Blade Down . . . . . . .864 lb. (392 kg)*
2,146 lb. (973 kg)*
2,865 lb. (1300 kg)*
5,190 lb. (2354 kg)*
Over Side . . . . . . . . . . . . . . . . . .470 lb. (213 kg)
960 lb. (435 kg)
1,455 lb. (660 kg)
2,151 lb. (976 kg)
*Limited by hydraulics.
Drive
Each track is independently driven by a hydrostatic axial-piston motor connected to a two-stage planetary gear reduction box.
Swing System
Swing Speed . . . . . . . . . . . . . . . . . . .8.6 rpm
8.9 rpm
8.9 rpm
9.0 rpm
Boom Swing
Left . . . . . . . . . . . . . . . . . . . . . . .65 degrees
66 degrees
66 degrees
60 degrees
Right . . . . . . . . . . . . . . . . . . . . . .50 degrees
66 degrees
66 degrees
80 degrees
Blade
Blade Width . . . . . . . . . . . . . . . . . . . .4 ft. 5.0 in. (1350 mm)
5 ft. 1.0 in. (1550 mm)
5 ft. 8.5 in. (1740 mm)
6 ft. 6.7 in. (2000 mm)
Blade Height . . . . . . . . . . . . . . . . . . .10.5 in. (270 mm)
15.2 in. (385 mm)
15.2 in. (385 mm)
15.2 in. (385 mm)
