Installing the Tweeter for the 652C
The separate tweeters included with the 652C have a variety of
mounting applications. During installation, make sure the tweeter
is positioned and aimed towards the listener's ears.
FIGURE 6 - WIRING THE SPEAKER/TWEETER
INSTALLATION
NOTE
There is a protective element integrated into the
crossover of your PowerPlus tweeter, which has
high impedance in cases of overload and reduces
the current flowing through the tweeter. If the
tweeter is deactivated, please turn down the
volume and wait for a moment. After cooling down,
the tweeter will re-activate and become ready for
operation again.
4
PowerPlus Speakers
FIGURE 5 - FLUSH MOUNTING FIGURE 4 - SURFACE MOUNTING
