ENGLISH

Using other external components

AV-INPUT

You can connect an external component to the LINE IN/VIDEO IN plugs.

Press [SOURCE], then press [AV-IN].

Turn on the connected component and start playing the source.

To display the operation buttons while watching the playback picture,

Navigation screen

You can also connect a Navigation System to the VIDEO IN plug so that you can watch the navigation screen.

Preparation:
Make sure <Navigation> is selected for <AV Input>. (

18)

To view the navigation screen

Press DISP on the monitor panel repeatedly.

• The aspect ratio of the navigation screen is fixed to <Full> regardless of the <Aspect> setting. (

15)

When <Navigation> is selected for <AV Input> (

18)

• You can use the source “AV-IN” for listening to an audio source connected to the LINE IN plugs.

Assigned title

(

22)

FLAT

SOURCE

AV-IN
