21
• For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed,
and may be slightly different from actual products.
• Design and specifications are subject to change without notice.
• All company names and product names mentioned herein are used for identification purposes only, and
may be the trademarks or registered trademarks of their respective companies.
Specifications
7 General
Model name DT-V24L3D DT-V20L3D
Type Multi format LCD monitor
Screen size Type 24 wide format Type 20 wide format
Aspect ratio 16:10
LCD panel 24˝ wide, active matrix TFT 20˝ wide, active matrix TFT
Effective screen size Width: 518.4 mm (17 1/16˝)
Height: 324 mm (10 5/8˝) Width: 433.4 mm (17 1/16˝)
Height: 270.9 mm (10 5/8˝)
Number of pixels displayed 1 920 x 1 200 1 680 x 1 050
Number of colors displayed 16.77 million
Viewing angle (TYP.) 176° (Horizontally), 176° (Vertically) 178° (Horizontally), 178° (Vertically)
Panel brightness (TYP.) 400 cd/m 2 470 cd/m 2
Contrast ratio (TYP.) 1000:1 700:1
Horizontal/vertical frequency
(computer signal) H: 31.469 kHz – 75.000 kHz
V: 48 Hz – 65 Hz
* Some signals within this frequency range may not be displayed (“Out of
range” is displayed).
Compliant video signal format ☞ “Available signals” on page 9
Format HD SDI: BTA S-004B, SMPTE292M
SD SDI: ITU-R BT.656: 525/625
SMPTE259M: 525
EMBEDDED AUDIO: SMPTE299M, SMPTE272M
Audio output Internal speaker: 1.0 W + 1.0 W
Operating conditions Operating temperature: 5°C – 35°C (41°F – 95°F)
Operating humidity: 20% – 80% (non-condensing)
(Slightly variable depending on ambient conditions for installation.)
Power requirements AC 120 V/AC 220 – 240 V, 50 Hz/60 Hz
Rated current 1.15 A (AC 120 V)
0.67 A (AC 220 – 240 V) 1.00 A (AC 120 V)
0.60 A (AC 220 – 240 V)
External dimensions
(excluding protruding parts) Width:
564 mm (22 1/4˝)
564 mm (22 1/4˝)
Height:
448.6 mm (17 3/4˝) 408 mm (16 1/8˝)
Depth:
243 mm (9 5/8˝)
99 mm (4˝)
(with the stand) (without the stand)
Width:
477 mm (18 7/8˝)
477 mm (18 7/8˝)
Height:
394.6 mm (15 5/8˝) 354 mm (14˝)
Depth:
243 mm (9 5/8˝)
99 mm (4˝)
(with the stand) (without the stand)
Weight 11.6 kg (25.5 lbs) (with the stand)
8.7 kg (19.1 lbs) (without the stand) 10.6 kg (23.3 lbs) (with the stand)
7.7 kg (16.9 lbs) (without the stand)
Accessories AC power cord, Power cord holder x 1, Screw x 2 (for power cord holder)
Notice on transportation
This monitor is precision equipment and needs dedicated packing material for transportation.
Never use any packing material supplied from sources other than JVC or JVC-authorized dealers.
7 Input/output terminals
Model name DT-V24L3D DT-V20L3D
Video
VIDEO (INPUT 1) Input/output of composite signal:
1 line, BNC connector x 2, 1 V(p-p), 75 Ω
VIDEO (INPUT 2) * The input (IN) and output (OUT) terminals are bridge-connected (auto
termination).
DVI-D (HDCP) DVI-D signal input (compatible with HDCP):
DVI-D connector x 1 (compatible with DDC2B)
COMPO./RGB (G/Y, B/P B /B-
Y, R/P R /R-Y)
Input/output of analog component signal/analog RGB signal:
1 line, BNC connector x 6
G/Y: 1 V(p-p), 75 Ω (including sync signal)
B/P B /B-Y, R/P R /R-Y: 0.7 V(p-p), 75 Ω
* The input (IN) and output (OUT) terminals are bridge-connected (auto
termination).
EXT.SYNC (CS) Input/output of composite sync signal:
1 line, BNC connector x 2,
0.3 V(p-p) – 4 V(p-p),
75 Ω (tri-level sync, negative polarity sync (bi-level), and BB)
(including no video signal)
* The input (IN) and output (OUT) terminals are bridge-connected (auto
termination).
E. AUDIO HD/SD SDI (IN 1) Digital signal input (compatible with EMBEDDED AUDIO signals):
auto detection, 1 line, BNC connector x 1 E. AUDIO HD/SD SDI (IN 2)
E. AUDIO HD/SD SDI
(SWITCHED OUT) Digital signal output (compatible with EMBEDDED AUDIO signals):
1 line switched out, BNC connector x 1
A
udio
AUDIO ASSIGN (IN 1) Analog audio signal input: 1 line, RCA connector x 2,
500 mV (rms), high impedance AUDIO ASSIGN (IN 2)
AUDIO ASSIGN
(MONITOR OUT) Analog audio signal output: 1 line, RCA connector x 2,
500 mV (rms)
External contr
ol
REMOTE (MAKE/TRIGGER) ☞ “Using the MAKE/TRIGGER system” on page 17
REMOTE (RS-485)
☞ “Using the serial communication” on page 18
REMOTE (RS-232C)
