77
HD-ILA Device Projection Type
Reception Format
Reception Range
Power Source
Power Consumption
Model
NTSC, BTSC System (Multi-Channel Sound)
ATSC Terrestrial, Digital Cable
VHF 2 to 13, UHF 14 to 69 CATV 125 Sub, Mid, Super, Hyper
and Ultra bands (181 channel frequency synthesizer system) at Analog
AC 120V, 60 Hz
205W
110W High-Pressure Mercury Lamp
Screen Size
Speakers 10 cm round X 2
Audio Output Full Range - 10W + 10W
Antenna Terminal
(VHF/UHF,
ATSC/DIGITAL
CABLE IN)
75 ohms (VHF/UHF)(F-type connector)
External Input Jacks
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBvfs) high impedance
Component Input
Jack
Y: 1Vp-p positive, 75 ohms (negative sync provided)
Pb/Pr: 0.7 Vp-p 75 ohms
S-Video Input Jacks
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Digital–In
HDMI jack x 2
Note: The Digital–In terminal is not compatible with picture signals of a
personal computer
Remote control unit x 1 / AA batteries X 2
Dimensions (inch)
W X H X D (cm)
Weight (lbs / kg)
Accessories
Audio Output Jacks
(FIX)
FIX : 500mVrms (-4dBvfs) Low impedance (1000 Hz when modulated 100%)
Projection Source
Optical Output
Digital Audio
Digital Out (optical) x 1
56 inch / 142.2 cm
measured diagonally,
16:9 ratio
52 x 38 1/8 x 17 3/8
131.8 x 96.8 x 43.9
90 / 41
• Reception of channel A-5 ("95" of the TV set's on-screen cable channel
numbers) is not recommended for your TV set.
HD-56GC87
VHF 2 to 13, UHF 14 to 69 at ATSC,
CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable
Specifications
Specifications subject to change without notice.
• The open source software is embedded in this product. For more information, please go to:
http://software.jvc.com/opensource/lnx/DP/06_AtscQam/download.html
