Cable Holder
A cable holder which keeps your connection cables tidy is attached on
the back of the stand. To open, loosen the screws with you fingers.
After putting the cables in the cable holder, attach it to the back of the
stand again by tightening the screws with your fingers.
Remove the terminal cover
There are connection terminals behind the cover on the left in the back
of the TV. Remove the cover before connecting an antenna or other
devices. The cover can be removed by removing the hooks. When
replacing the cover, place the side of the cover against the TV and
insert the hooks.
Note:
• Leave the terminal cover off if they do not fit properly. Do not force
to replace the cover. Doing so may damage the connection cables
and cover.
Quick Setup
TV Rear Panel
Cable or Antenna
Output
Coaxial Cable
(Attachment)
No VCR Connection
