Fig. 1 – Jura Capresso IMPRESSA C9 User Manual
Page 4
1.
Height-Adjustable Coffee Spout
2.
Left Button Cluster and Rotary Dial (See Fig. 3)
3.
Removable Water Tank
4.
Low Water Flotation Device (See Fig. 7.4)
5.
Clearyl Water Care Cartridge*
6.
Lid for Water Tank
7.
Ground Coffee Funnel
8.
Lid for Ground Coffee Funnel
9.
Lid for Bean Container
10.
Bean Container / fineness selector (See Fig. 5 and 6)
11.
Right Button Cluster (See Fig. 4)
12.
Auto-Cappuccino System with frothXpress and
Milk Container
13.
Stainless Steel Cup Platform
14.
Removable Drawer
15.
Measuring Scoop
16.
Two Cleaning Tablets (white)
17.
Water Hardness Indicator Strip
18.
Clearyl Water Cartridge (unpacked)
Fig. 1
8
7
6
5
4
3
2
1
9
10
11
12
13
14
15 16 17 18
19. Used Coffee Container
20. Tray
13. Cup Platform
14. Drawer
Fig. 2
4.
*
Attention: The Water Filter Cartridge should be in a pouch.
If your machine comes with the cartridge installed, it is not a new machine!
Call customer service 1-800-220-5701.
Fig. 1a
Main Power Switch
located in back
next to power cord
